Compressor Nameplate
The compressor assembly has a separate model number
which is required to identify internal and external
compressor parts. The model number begins with “HDMA”
and the nameplate is located on the interstage pipe; refer
to “,”.
Figure 2. Compressor nameplate
Note: Do NOT cover compressor nameplate with wrap or
insulation (leave a window).
Unit Nameplate
