HDWA-SVX002C-EN
37
WARNING
Personal Protective Equipment (PPE)
Required!
Failure to wear PPE and follow proper handling
guidelines could result in death or serious injury.
Always wear appropriate personal protective
equipment in accordance with applicable regulations
and/or standards to guard against potential electrical
shock and flash hazards.
WARNING
Live Electrical Components!
Failure to follow all electrical safety precautions when
exposed to live electrical components could result in
death or serious injury.
When it is necessary to work with live electrical
components, have a qualified licensed electrician or
other individual who has been properly trained in
handling live electrical components perform these
tasks.
Adaptive Frequency Drive
Table 15. Adaptive Frequency Drive (AFD) electrical
data — Tmax circuit breakers 460/480 and
575/600 volts
Input
Voltage
Maximum
RLA
Tmax
Breaker
AIC Amps
Short Circuit
Withstand
Rating
Line
Connection
Lugs
460V /
60Hz
678
65,000 65,000
(4) 4/0 - 500
MCM
535
65,000 65,000
(3) 2/0 - 400
MCM
443
65,000 65,000
(2) 3/0 - 250
MCM
361
65,000 65,000
(2) 3/0 - 250
MCM
240
65,000 65,000
(2) 3/0 - 250
MCM
575V /
60Hz
678
65,000 65,000
(3) 2/0 - 400
MCM
535
65,000 65,000
(2) 3/0 - 250
MCM
443
65,000 65,000
(2) 3/0 - 250
MCM
361
65,000 65,000
(2) 3/0 - 250
MCM
240
65,000 65,000
(2) 3/0 - 250
MCM
Table 16. Adaptive Frequency Drive (AFD) electrical
data — XT circuit breakers 460/480 and 575/
600 volts
Input
Voltage
Maximum
RLA
XT Breaker
AIC Amps
Short Circuit
Withstand
Rating
Line
Connection
Lugs
460V /
60Hz
678
65,000 65,000
(4) 4/0 - 500
MCM
535
65,000 65,000
(3) 2/0 - 400
MCM
443
65,000 65,000
(2) 2/0 - 500
MCM
361
65,000 65,000
(2) 2/0 - 500
MCM
240
65,000 65,000
(2) 2/0 - 500
MCM
575V /
60Hz
678
65,000 65,000
(4) 4/0 - 500
MCM
535
65,000 65,000
(2) 2/0 - 500
MCM
443
65,000 65,000
(2) 2/0 - 500
MCM
361
65,000 65,000
(2) 2/0 - 500
MCM
240
65,000 65,000
(2) 2/0 - 500
MCM
The main circuit breaker within the AFD panel is affixed
with a dial, labeled “Ir”, to set the trip current of the breaker.
See tables below for the factory “Ir” dial setting for 400 amp
and 600 amp (L-frame) circuit breakers, and for the 800
amp and 1200 amp (P-frame) circuit breaker “Ir” dial
settings. These values are based on the panel SRRL and
IVLT values found on the unit nameplate.
Table 17. Breaker Ir dial setting, L-frame breakers(400
and 600 amp)
Breaker Ir Dial
Setting
IVLT
575/
600
460/
480
380/
400/
415
208
SRRL
532/533 600 - - -
439/440 500 600 600 -
362/363 400 500 500 -
238/243 300 400 - -
Table 18. Breaker Ir dial setting, P-frame breakers(800
and 1200 amp)
Breaker Ir Dial
Setting
IVLT
575/
600
460/
480
380/
400/
415
208
SRRL
675 0.9 0.9 0.9 -
532 - 1 1 -
439/440 - - - 1
362/363 - - - 0.9
Electrical Requirements
