Data Name
Run Time
15 Minutes 30 Minutes 1 Hour
Evaporator
Active Chilled Water Setpoint
Evaporator Entering Water Temperature
Evaporator Leaving Water Temperature
Evaporator Approach Temperature
Evaporator Saturated Rfgt Temp
Evaporator Refrigerant Pressure
Evaporator Water Flow Status
Approximate Evaporator Water Flow
Evaporator Water Pump Override
Evaporator Differential Water Pressure
Evaporator EXV Percent Open
Condenser
Active Hot Water Setpoint
Condenser Entering Water Temperature
Condenser Leaving Water Temperature
Condenser Approach Temperature
Condenser Saturated Rfgt Temp
Condenser Refrigerant Pressure
Condenser Water Flow Status
Approximate Condenser Water Flow
Condenser Water Pump Override
Condenser Differential Water Pressure
Differential Refrigerant Pressure
Condenser Refrigerant Liquid Level
Compressor
Compressor Running Status
Compressor Starts
Compressor Running Time
Chiller Load Command
Compressor Discharge Temperature
IGV Percent Open
Compressor Bearing Temperature 1
Compressor Bearing Temperature 2
MBC PCB Temperature
MBC Cooling Valve Percent Open
Motor
Active Demand Limit Setpoint
Percent Chiller Power
AFD Percent Speed
AFD Average Motor Current % RLA
AFD Calculated Motor Voltage
Chiller Load Command
AFD Motor Current U % RLA
AFD Motor Current V % RLA
AFD Motor Current W % RLA
AFD Motor Current U
AFD Motor Current V
Appendix D: Operator Log
