Trane Agility HDWA - Unit Specifications-International; System (SI) Units

HDWA-SVX001D-EN
15
Unit Specifications—International
System (SI) Units
Weights (kg)
IImmppoorrttaanntt:: The weight information provided here
should be used for general information
only. For specific weights for your chiller,
refer to your submittal package.
Table 3. Agility chiller weights (kg)
Shell
Shipping Weight
Operat-
ing
Weight
With
Refriger-
ant
Without
Refriger-
ant
020
Minimum 4591 4352 4980
Maximum 5592 5353 5836
040
Minimum 5775 5412 6425
Maximum 6845 6481 7650
Notes:
1. All weights ±5 percent.
2. Shipping weights include standard 1034.2 kPaG waterboxes.
3. Operating weights include refrigerant, glycol, and water
charges.
4. Optional waterbox hinges: each waterbox hinge weights 44 lb
(19.94 kg).
Center of Gravity (mm)
Table 4. Agility chiller center of gravity (mm)
Shipping Operating
X Y Z X Y Z
Mini-
mum
742 793 1007 752 743 1011
Maxi-
mum
804 826 1190 816 781 1178
Notes:
1. All weights ±5 percent.
2. Shipping weights include standard 1034.2 kPaG waterboxes.
3. Operating weights include refrigerant, glycol, and water
charges.
