Trane Agility HDWA - Start-up and Shut-down Procedures; Unit Start-up Procedures

HDWA-SVX001D-EN
61
Unit Start-up and Shut-down
Procedures
WWAARRNNIINNGG
LLiivvee EElleeccttrriiccaall CCoommppoonneennttss!!
FFaaiilluurree ttoo ffoollllooww aallll eelleeccttrriiccaall ssaaffeettyy pprreeccaauuttiioonnss
wwhheenn eexxppoosseedd ttoo lliivvee eelleeccttrriiccaall ccoommppoonneennttss ccoouulldd
rreessuulltt iinn ddeeaatthh oorr sseerriioouuss iinnjjuurryy..
WWhheenn iitt iiss nneecceessssaarryy ttoo wwoorrkk wwiitthh lliivvee eelleeccttrriiccaall
ccoommppoonneennttss,, hhaavvee aa qquuaalliiffiieedd lliicceennsseedd eelleeccttrriicciiaann
oorr ootthheerr iinnddiivviidduuaall wwhhoo hhaass bbeeeenn pprrooppeerrllyy ttrraaiinneedd
iinn hhaannddlliinngg lliivvee eelleeccttrriiccaall ccoommppoonneennttss ppeerrffoorrmm
tthheessee ttaasskkss..
WWAARRNNIINNGG
AAsspphhyyxxiiaattiioonn HHaazzaarrdd!!
AA ssiiggnniiffiiccaanntt rreelleeaassee ooff rreeffrriiggeerraanntt iinnttoo aa ccoonnffiinneedd
ssppaaccee ccoouulldd ddiissppllaaccee aavvaaiillaabbllee ooxxyyggeenn ttoo bbrreeaatthhee
aanndd ccaauussee ppoossssiibbllee aasspphhyyxxiiaattiioonn.. FFaaiilluurree ttoo ffoollllooww
iinnssttrruuccttiioonnss bbeellooww ccoouulldd rreessuulltt iinn ddeeaatthh oorr sseerriioouuss
iinnjjuurryy..
SShhoouulldd aa rreeffrriiggeerraanntt rreelleeaassee ooccccuurr,, eevvaaccuuaattee tthhee
aarreeaa iimmmmeeddiiaatteellyy aanndd ccoonnttaacctt tthhee aapppprroopprriiaattee
rreessccuuee oorr rreessppoonnssee aauutthhoorriittyy..
•• DDoo nnoott rruunn eevvaappoorraattoorr wwaatteerr ppuummpp lloonnggeerr tthhaann
3300 mmiinnuutteess aafftteerr tthhee cchhiilllleerr iiss sshhuutt ddoowwnn..
•• EEnnssuurree tthhaatt tthhee eevvaappoorraattoorr iiss iissoollaatteedd ffrroomm tthhee
hhoott wwaatteerr lloooopp bbeeffoorree cchhaannggeeoovveerr ttoo hheeaattiinngg
mmooddee..
TThhee rreelliieeff ddeevviiccee iiss ddeessiiggnneedd ttoo rreelliieevvee aanndd
ddiisscchhaarrggee tthhee rreeffrriiggeerraanntt ffrroomm tthhee uunniitt iiff tthhee
pprreessssuurree iinn tthhee eevvaappoorraattoorr eexxcceeeeddss 220000 ppssiigg
((11337799..00 kkPPaaGG)) oonn tthhee eevvaappoorraattoorr oorr 330000 ppssiigg
((22006688..44 kkPPaaGG)) oonn tthhee ccoonnddeennsseerr..
Unit Start-up
NNOOTTIICCEE
EEqquuiippmmeenntt DDaammaaggee!!
FFaaiilluurree ttoo ffoollllooww iinnssttrruuccttiioonnss ccoouulldd rreessuulltt iinn
eeqquuiippmmeenntt ddaammaaggee..
EEnnssuurree tthhaatt tthhee UUnniinntteerrrruuppttiibbllee PPoowweerr SSuuppppllyy
((UUPPSS)) hhaass bbeeeenn ooppeerraattiinngg pprrooppeerrllyy ffoorr aa mmiinniimmuumm
ooff 1100 hhoouurrss bbeeffoorree ssttaarrttiinngg..
If required, after the system has been operating for
approximately 30 minutes and has become stabilized,
complete the remaining start-up procedure, as follows:
1. Check evaporator and condenser refrigerant
pressures under Condenser and Evaporator Reports
on the Tracer® AdaptiView™. The pressures are
referenced to sea level (14.6960 psia [101.3254
kPaA]).
Temporary Shut-down and Restart
To shut down for a short time, use the following
procedure:
1. Press the STOP key on the Tracer® AdaptiView™.
2. UC800 pump control will turn off the pump (after a
optional water pump delay time) when the STOP
key is pressed and automatically restart the pump
when the “Auto” key is pressed.
3. The unit will start normally, provided the following
conditions exist:
a. The UC800 receives a call for cooling and the
differential-to-start is above the setpoint.
b. All system operating interlocks and safety
circuits are satisfied.
Extended Unit Shut-down
1. Perform the normal unit stop sequence using the
STOP key.
NNoottee:: Unless the water bundles are valved off and
drained, chiller power should remain ON at
all times to allow the magnetic bearings to
levitate the rotor in case water flow-driven
rotation should occur. Trane recommends
leaving the power on to maintain the
Uninterruptible Power Supply (UPS) battery.
2. Verify the chilled water and condenser water
pumps are cycled off. If desired, open disconnect
switches to the pumps.
3. Drain the condenser piping and cooling tower.
4. Remove the drain and vent plugs from the
condenser headers to drain the condenser.
5. After the unit is secured, perform the maintenance
identified in the following sections.
Seasonal Unit Start-up
1. Close all drain valves and reinstall the drain plugs in
the evaporator and condenser headers.
2. Service the auxiliary equipment according to the
start-up and maintenance instructions provided by
the respective equipment manufacturers.
3. Vent and fill the cooling tower, if used, as well as
the condenser and piping. At this point, all air must
be removed from the system (including each pass).
Then, close the vents in the condenser chilled water
circuits.
4. Open all of the valves in the evaporator chilled
water circuit.
5. If the evaporator was previously drained, vent and
fill the evaporator and chilled water circuit. After all
air is removed from the system (including each
pass), install the vent plugs in the evaporator
waterboxes.
SSttaarrtt--uupp aanndd SShhuutt--ddoowwnn
