Product Overview
Tracer SC Accessories
Tracer SC Service Parts
The service parts listed in Table 1 and Table 2 are available for theTracer SC.The numbers in the
tables correspond to those in Figure 2.
Note: Some of the service parts are the same for all models.
Description Order number
BACnet terminator 2 pack
(a)
(a)For information about this accessory, see BACnet MS/TP Wiring Best Practices (BAS-SVX051-EN).
X1365152401
Rover LonTalk interface adaptor
(b)
(b)For information about this accessory, see Rover Service Tool Installation, Operation, and Programming (EMTX-SVX01).
S3090062062
Table 1. Tracer SC model BMSC0 00AAA011000 (current)
Number in
Figure 2 Description Order number
1 Enclosure for DIN-mounted controllers (120 VAC, with outlet) X13651559010
2 Tracer SC module S3090058462
3 Power supply module X1365153801
(not shown) Enclosure for DIN-mounted controllers (230 VAC, no outlet) X13651560010
(not shown) Transformer service part S3090062462
4 IMC power cable S3090059562
(not shown)
Large enclosure for DIN-mounted controllers, 120 VAC, with outlet
(solid door)
X13651552-01
(not shown)
Large enclosure for DIN-mounted controllers, 120 VAC, with outlet
(display-capable door)
X13651553-01
(not shown)
Large enclosure for DIN-mounted controllers, 230 VAC, with outlet
(display-capable door)
X13651554-01
(not shown)
Large enclosure for DIN-mounted controllers, 230
VAC, with outlet (display-capable door)
X13651555-01
Table 2. Tracer SC models BMSC000AAA011100 and BMSC000AAA011200 (obsolete)
Number in
Figure 2 Description Order number
2 Tracer SC module S3090058462
3 Power supply module S3090058562
4 IMC power cable S3090059562
5 Cable assembly/modular terminal kit with U.S. outlet S3090059062
(not shown) Cable assembly/modular terminal kit S3090059162
6 Control panel cover (for models with U.S. outlet) S3090058962
(not shown) Control panel cover S3090058862
7 Enclosure S3090058762
