Trane IntelliPak User Manual

Unit Start Up
RT-SVX36K-EN 121
Table 50. 20-89 tons - modulating 100% exhaust fan performance
Nominal Cfm Negative Static Pressure
Tons Std 0.250 0.500 0.750 1.000 1.250 1.500 1.750 2.000
(AC/EC) Air RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
20/24
4000
379 0.34 515 0.70 622 1.12 712 1.59 791 2.10 861 2.64
6000
421 0.61 541 1.03 643 1.52 732 2.07 811 2.66
8000 487 1.10 583 1.56 674 2.11 757 2.72
10000 567 1.88 643 2.37 719 2.96
25/29
4000
379 0.34 515 0.70 622 1.12 712 1.59 791 2.10 861 2.64 927 3.22 988 3.84
6000
421 0.61 541 1.03 643 1.52 732 2.07 811 2.66 882 3.28 948 3.94 1010 4.64
8000 487 1.10 583 1.56 674 2.11 757 2.72 834 3.38 904 4.09 970 4.82
10000 567 1.88 643 2.37 719 2.96 794 3.63 864 4.35
12000 651 2.98 716 3.56 779 4.18 843 4.88
30/36
4000
379 0.34 515 0.70 622 1.12 712 1.59 791 2.10 861 2.64 927 3.22 988 3.84
6000
421 0.61 541 1.03 643 1.52 732 2.07 811 2.66 882 3.28 948 3.94 1010 4.64
8000 487 1.10 583 1.56 674 2.11 757 2.72 834 3.38 904 4.09 970 4.82 1030 5.59
10000 567 1.88 643 2.37 719 2.96 794 3.63 864 4.35 931 5.11 993 5.91 1053 6.77
12000 651 2.98 716 3.56 779 4.18 843 4.88 905 5.64 967 6.47 1026 7.34
14000 736 4.47 796 5.17 850 5.83 904 6.57 960 7.38
40/48
7500
318 0.67 444 1.21 545 1.85 629 2.54 702 3.27 767 4.02 828 4.83 884 5.66
9000
331 0.97 444 1.47 543 2.17 628 2.94 702 3.75 770 4.60 831 5.48 887 6.37
12000 381 2.13 460 2.40 546 3.04 627 3.89 701 4.83 769 5.82 831 6.87
889 7.93
14000 422 3.40 486 3.49 557 3.98 631 4.76 701 5.72 768 6.78 830 7.90
888 9.07
16000
468 5.12 520 5.07 579 5.37 643 6.01 707 6.88 769 7.92 829 9.08 887 10.32
50/59
9000
331 0.97 444 1.47 543 2.17 628 2.94 702 3.75 770 4.60 831 5.48 887 6.37
12000 381 2.13 460 2.40 546 3.04 627 3.89 701 4.83 769 5.82 831 6.87
889 7.93
15000 445 4.20 502 4.21 567 4.61 636 5.32 704 6.26 769 7.32 830 8.47
888 9.67
18000
516 7.41 559 7.19 609 7.32 662 7.76 719 8.49 776 9.44 833 10.56 887 11.79
20000 566 10.31
602 9.91 644 9.88 690 10.15 739 10.69 789 11.48 841 12.48 893 13.68
60/73
70/80
75/89
12000
351 1.49 423 2.09 502 3.00 572 4.02 634 5.07 690 6.09 740 7.04 784 7.91
15000 412 2.68 460 3.15 521 3.96 585 5.02 646 6.24 702 7.53 749 8.83 801 10.14
18000 478 4.41 516 4.88 557 5.54 607 6.49 662 7.66 715 9.01 766 10.48 814 12.01
21000 549 6.75 578 7.36 612 7.92 647 8.71 688 9.77 735 11.03 781 12.46 827 14.03
24000 617 9.83 644 10.59 672 11.22 702 11.88 732 12.77 766 13.89 805 15.22 846 16.72
27000
688 15.11 711 15.09 736 15.45 761 16.18 788 17.02 815 17.92 844 18.99 876 20.31
Note: Shaded areas indicate non-standard drive selections. These drive selections must be manually factory selected.

Trane IntelliPak Specifications

General

Refrigerant	R-410A
Compressor Type	Scroll
Voltage	208/230/460V, 3-phase
Type	Rooftop Unit
Airflow Configuration	Horizontal
Sound Level	Varies by model
Control System	Tracer
Dimensions	Varies with model
Weight	Varies with model
Heating Capacity	Optional electric or gas
