Trane IntelliPak User Manual

184 RT-SVX36K-EN
Unit Wiring Diagram Numbers
Note: Wiring diagrams can be accessed via e-Library by entering the diagram number in the literature order number
search field or by calling technical support.
Table 81. Wiring diagram matrix
Air Cooled
Water
Cooled
Tonnage Description
Power
VAV & SZVAV 2313-1042 20, 30-75T SCHEMATIC W/ SUP VFD
2313-1043 20, 30-75T SCHEMATIC W/ EXH/RET VFD
2313-1044 20, 30-75T SCHEMATIC W/ SUP & EXH/RET VFD
2313-1047 25T SCHEMATIC W/ SUP VFD
2313-1048 25T SCHEMATIC W/ EXH/RET VFD
2313-1049 25T SCHEMATIC W/ SUP & EXH/RET VFD
2313-1052 90-130T SCHEMATIC W/ SUP VFD
2313-1053 90-130T SCHEMATIC W/ EXH VFD
2313-1054 90-130T SCHEMATIC W/ SUP & EXH VFD
2313-1089 24, 36-89T SCHEMATIC EVAP COOLED W/ SUP VFD
2313-1090 24, 36-89T SCHEMATIC EVAP COOLED W/ EXH/RET VFD
2313-1091 24, 36-89T SCHEMATIC EVAP COOLED W/ SUP & EXH/RET VFD
2313-1094 29T SCHEMATIC EVAP COOLED W/ SUP VFD
2313-1095 29T SCHEMATIC EVAP COOLED W/ EXH/RET VFD
2313-1096 29T SCHEMATIC EVAP COOLED W/ SUP & EXH/RET VFD
CV 2313-1041 20, 30-75T SCHEMATIC STD
2313-1046 25T SCHEMATIC STD
2313-1051 90-130T SCHEMATIC STD
2313-1194 24, 36-89T SCHEMATIC EVAP COOLED STD
2313-1093 29T SCHEMATIC EVAP COOLED STD
RTM
VAV & SZVAV 2313-1125 20-89T SCHEMATIC W/ SUP VFD
2313-1126 20-89T SCHEMATIC W/ EXH/RET VFD
2313-1127 20-89T SCHEMATIC W/ SUP & EXH/RET VFD
2313-1130 90-130T SCHEMATIC W/ SUP VFD
2313-1131 90-130T SCHEMATIC W/ EXH VFD
2313-1132 90-130T SCHEMATIC W/ SUP & EXH VFD
CV 2313-1124 20-89T SCHEMATIC STD
2313-1129 90-130T SCHEMATIC STD
Compressor Module
(SCM/MCM) & MDM
2313-1017 20-30T SCHEMATIC STD OR W/ SUP OR W/ EXH/RET VFD
2313-1018 40-75T SCHEMATIC STD OR W/ SUP OR W/ EXH/RET VFD
2307-9188 90-130T SCHEMATIC STD OR W/ SUP OR W/ EXH VFD
2313-1016 24-89T SCHEMATIC EVAP COOLED
Heat & GBAS 2307-3891 20-130T SCHEM STD OR W/ EXH/RET VFD, ELEC/2-STG GAS/HYDRONIC HT
2307-3892 20-130T
SCHEMATIC W/ SUP VFD OR W/ SUP & EXH/RET VFD ELEC/2-STG
GAS/HYDRONIC HT
2307-3955 20-130T SCHEMATIC STD OR W/ EXH/RET VFD, MODULATING GAS HT
2307-3956 20-130T
SCHEMATIC W/ SUP VFD OR W/ SUP & EXH/RET VFD MODULATING
GAS HEAT
Control Options 2313-1013 20-130T SCHEMATIC STD OR W/ SUP VFD
2313-1014 20-130T SCHEMATIC W/ EXH/RET VFD OR W/ SUP & EXH/RET VFD
