Trane IntelliPak User Manual

Unit Wiring Diagram Numbers
RT-SVX36K-EN 185
VFD Schematics
TR200 2309-3577 90-130T SCHEMATIC/CONNECTION SUP VFD #1 W/ BYPASS
2309-3578 90-130T SCHEMATIC/CONNECTION EXH/RET VFD W/ BYPASS
2309-3579 90-130T SCHEMATIC/CONNECTION SUP VFD #2 W/ BYPASS
2309-3581 90-130T SCHEMATIC/CONNECTION SUP VFD #1 W/O BYPASS
2309-3582 90-130T SCHEMATIC/CONNECTION EXH/RET VFD W/O BYPASS
2309-3583 90-130T SCHEMATIC/CONNECTION SUP VFD #2 W/O BYPASS
TR150 2313-1944 20-89T SCHEMATIC/CONNECTION SUP VFD W/O BYPASS
2313-1945 20-89T SCHEMATIC/CONNECTION SUP VFD W/ BYPASS
2313-1946 20-89T SCHEMATIC/CONNECTION EXH/RET VFD W/O BYPASS
2313-1947 20-89T SCHEMATIC/CONNECTION EXH/RET VFD W/ BYPASS
TRV200 2313-1175 40-70T SCHEMATIC/CONNECTION COMPRESSOR VFD
Heat
Electric 2306-8932 20-89T SCHEMATIC ELECTRIC HEAT 460/575V 2 CKT
2306-8933 20-89T SCHEMATIC ELECTRIC HEAT ALL VOLTAGES 3 CKT
2306-8934 30-89T SCHEMATIC ELECTRIC HEAT ALL VOLTAGES 6 CKT
2306-8935 30-89T SCHEMATIC ELECTRIC HEAT 200V 7 CKT
2306-8934 90-130T SCHEMATIC ELECTRIC HEAT 460/575V 6 CKT 190KW
2307-2171 20-89T CONN ELEC HT 460/575V 2 CKT-3 OR 1 STEP SEE NOTE 6
2307-2172 20-89T CONN ELEC HT ALL VOLTAGES 3 CKT-3 OR 1 STEP
2307-2173 20-89T CONN ELEC HT ALL VOLTAGES 6 CKT-3 OR 1 STEP
2307-2174 30-89T CONN ELEC HT 200V 7 CKT-3 OR 1 STEP
2307-2175 90-130T CONN ELEC HT 460/575V 6 CKT - 190KW SEE NOTE 7
Gas 2313-1011 20-130T SCHEMATIC/CONNECTION 2-STAGE NAT GAS HEAT 235-1000 MBh
2307-9103 20-130T
SCHEMATIC/CONNECTION MODULATING NAT GAS HEAT 500, 850 &
1000 MBh
Control Box Connections
VAV/SZVAV 2313-1135 20-30T CONNECTION W/ SUP VFD
2313-1136 20-30T CONNECTION W/ EXH/RET VFD
2313-1137 20-30T CONNECTION W/ SUP & EXH/RET VFD
2313-1140 40-75T CONNECTION W/ SUP VFD
2313-1141 40-75T CONNECTION W/ EXH/RET VFD
2313-1142 40-75T CONNECTION W/ SUP & EXH/RET VFD
2313-1145 90-130T CONNECTION W/ SUP VFD
2313-1146 90-130T CONNECTION W/ EXH VFD
2313-1147 90-130T CONNECTION W/ SUP & EXH VFD
2313-1150 24-89T CONNECTION EVAP COOLED W/ SUP VFD
2313-1151 24-89T CONNECTION EVAP COOLED W/ EXH/RET VFD
2313-1152 24-89T CONNECTION EVAP COOLED W/ SUP & EXH/RET VFD
Module Connections 2313-1155 20-30T CONNECTION W/ SUP VFD
2313-1156 20-30T CONNECTION W/ EXH/RET VFD
2313-1157 20-30T CONNECTION W/ SUP & EXH/RET VFD
2313-1159 40-75T CONNECTION W/ SUP VFD
2313-1160 40-75T CONNECTION W/ EXH/RET VFD
2313-1161 40-75T CONNECTION W/ SUP & EXH/RET VFD
Table 81. Wiring diagram matrix (continued)
Air Cooled
Water
Cooled
Tonnage Description

Trane IntelliPak Specifications

General

Refrigerant	R-410A
Compressor Type	Scroll
Voltage	208/230/460V, 3-phase
Type	Rooftop Unit
Airflow Configuration	Horizontal
Sound Level	Varies by model
Control System	Tracer
Dimensions	Varies with model
Weight	Varies with model
Heating Capacity	Optional electric or gas
