Installation
36 RT-SVX36K-EN
Trane Roof Curb and Ductwork
The roof curbs for 20 through 130Ton units consists of two
main components; a pedestal to support the unit’s
condenser section and a “full perimeter” enclosure to
support the unit’s air handler section.
Before installing any roof curb, verify;
1. That it is the correct curb for the unit,
2. That it includes the necessary gaskets and hardware,
3. That the purposed installation location provides the
required clearance for proper operation.
4. Insure that the curb is level and square.The top surface
of the curb must be true to assure an adequate curb-to-
unit seal.
Step-by-step curb assembly and installation instructions
ship with eachTrane accessory roof curb kit. Follow the
instructions carefully to assure proper fit-up when the unit
is set into place.
Table 14. Evaporative condenser - approximate operating weights (lbs/kg)
Without Exhaust Fan With Exhaust Fan
Unit SX SE SF SL/SS SX SE SF SL/SS
24
lbs 6549 6679 6944 6763 6907 7037 7302 7121
kg 2971 3030 3150 3068 3133 3192 3312 3230
29
lbs 6599 6729 6994 6813 6963 7093 7358 7177
kg 2993 3052 3172 3090 3158 3217 3338 3255
36
lbs 7121 7251 7513 7335 7538 7668 7933 7752
kg 3230 3289 3409 3327 3419 3478 3598 3516
48
lbs 9001 9156 9631 9359 9585 9740 10215 9943
kg 4083 4153 4369 4245 4348 4418 4633 4510
59
lbs 9213 9368 9843 9571 9856 10011 10486 10214
kg 4179 4249 4465 4341 4471 4541 4756 4633
73
lbs 11303 11458 11933 11691 12128 12283 12758 12516
kg 5127 5197 5413 5303 5501 5571 5787 5677
80
lbs 11430 11585 12060 11818 12255 12410 12885 12643
kg 5185 5255 5470 5361 5559 5629 5845 5735
89
lbs 11820 11975 12450 12208 12645 12800 13275 13033
kg 5361 5432 5647 5537 5736 5806 6021 5912
Notes:
1. Weights shown for evaporative condensing units include the following features: FC fans, high capacity evaporative coil. Add 520 lbs for 24, 29, 36, 48
and 59 units and 680 lbs for 73, 80 and 89 units for installed sump base water weight for evaporative condenser total operating weight.
2. Weights shown represent approximate operating weights and have a ±5% accuracy. To calculate weight for a specific unit configuration, utilize TOPSS
or contact the local Trane sales representative. ACTUAL WEIGHTS ARE STAMPED ON THE UNIT NAMEPLATE.
Table 15. Roof curb max weight
(a)
Unit
Roof Curb Max. Weight
Unit
Roof Curb Max. Weight
SAHL S*HL SAHL S*HL
20/24
490 510
70/80
610 640
222 231 277 290
25/29
490 510
75/89
610 640
222 231 277 290
30/36
490 510
90
N/A 770
222 231 N/A 349
40/48
515 550
105
N/A 770
234 249 N/A 349
50/55/59
515 550
115
N/A 770
234 249 N/A 349
60/73
515 550
130
N/A 770
234 249 N/A 349
(a)Roof curb weights include the curb and pedestal.
