Trane IntelliPak User Manual

Installation
RT-SVX36K-EN 35
Table 13. Air-cooled condenser - approximate operating weights (Lbs./Kg)
Unit
Without Exhaust Fan With Exhaust Fan
SA SX SE SF SL/SS SA SX SE SF SL/SS
20
Lb 4092 4422 4712 4422 4312 4390 4720 5010 4720 4610
Kg 1856 2006 2137 2006 1956 1991 2141 2272 2141 2091
25
Lb 4181 4521 4791 4521 4391 4485 4825 5095 4825 4695
Kg 1896 2050 2173 2050 1992 2034 2188 2311 2188 2129
30
Lb 4572 4932 5202 4932 4812 5029 5389 5659 5389 5269
Kg 2074 2237 2359 2237 2183 2281 2444 2567 2444 2390
40
Lb 6433 6737 7217 6737 6577 7103 7407 7887 7407 7247
Kg 2918 3056 3273 3056 2983 3222 3360 3577 3360 3287
50
Lb 7175 7725 8185 7725 7555 7894 8444 8904 8444 8274
Kg 3255 3504 3713 3504 3427 3581 3830 4039 3830 3753
55
Lb 7425 7975 8455 7975 7815 8144 8694 9174 8694 8534
Kg 3368 3617 3835 3617 3545 3694 3944 4161 3944 3871
60
Lb 8338 8658 9118 8658 8498 9282 9602 10062 9602 9442
Kg 3782 3927 4136 3927 3855 4210 4355 4564 4355 4283
70
Lb 8604 8666 9146 8666 8516 9547 9609 10089 9609 9459
Kg 3903 3931 4148 3931 3863 4330 4358 4576 4358 4290
75
Lb 8843 9173 9653 9173 9023 9786 10116 10596 10116 9966
Kg 4011 4161 4379 4161 4093 4439 4589 4806 4589 4521
90
Lb. N/A 12649 12799 13439 12919 N/A 13989 14139 14779 14259
Kg N/A 5737 5805 6096 5860 N/A 6345 6413 6704 6468
105
Lb. N/A 13259 13409 14049 13529 N/A 14599 14749 15389 14869
Kg N/A 6014 6082 6372 6137 N/A 6622 6690 6980 6744
115
Lb. N/A 13449 13629 14289 13649 N/A 14789 14969 15629 14989
Kg N/A 6100 6182 6481 6191 N/A 6708 6790 7089 6799
130
Lb. N/A 13899 14059 14699 14089 N/A 15239 15399 16039 15429
Kg N/A 6304 6377 6667 6391 N/A 6912 6985 7275 6998
Notes:
1. Weights shown for air-cooled units include the following features: FC fans, standard coils, 100% economizer, throw-away filters, maximum motor
sizes 460V XL, high heat.
2. Weights shown represent approximate operating weights and have a ±5% accuracy. To calculate weight for a specific unit configuration, utilize
TOPSS™ or contact the local Trane sales representative. ACTUAL WEIGHTS ARE STAMPED ON THE UNIT NAMEPLATE.
