Trane IntelliPak User Manual

Unit Start Up
136 RT-SVX36K-EN
Figure 95. 40 ton high efficiency operating pressure curve (all compressors and condenser fans “On”)
200
250
300
350
400
450
500
90 100 110 120 130 140 150 160 170 180
Discharge Pressure, PSIG
Sucon Pressure, PSIG
105
o
FAmbient
95
o
FAmbient
85
o
FAmbient
75
o
FAmbient
65
o
FAmbient
Figure 96. 40 ton eFlex variable speed - circuit 1 only operating pressure curve (compressor at 100% and all condenser
fans “On”). See Figure 94 for circuit 2 operating pressures.
200
250
300
350
400
450
500
90 100110120130140150160170180
Discharge Pressure, PSIG
Sucon Pressure, PSIG
105
o
FAmbient
95
o
FAmbient
85
o
FAmbient
75
o
FAmbient
65
o
FAmbient

Trane IntelliPak Specifications

General

Refrigerant	R-410A
Compressor Type	Scroll
Voltage	208/230/460V, 3-phase
Type	Rooftop Unit
Airflow Configuration	Horizontal
Sound Level	Varies by model
Control System	Tracer
Dimensions	Varies with model
Weight	Varies with model
Heating Capacity	Optional electric or gas
