8 RT-SVX36K-EN
Model Number Descriptions
DIGIT 14 - SUPPLY AIR FAN HP
DIGIT 15 - SUPPLY AIR FAN RPM
DIGIT 16 - OUTSIDE AIR
Note: Must install CO
2
sensor(s) for DCV
to function properly
DIGIT 17 - SYSTEM CONTROL
1 = 3 HP FC
2 = 5 HP FC
3 = 7.5 HP FC
4 = 10 HP FC
5 = 15 HP FC
6 = 20 HP FC
7 = 25 HP FC
8 = 30 HP FC
9 = 40 HP FC
A = 50 HP FC
B = 3 HP DDP 80W
C = 3 HP DDP 120W
D = 5 HP DDP 80W
E = 5 HP DDP 120W
F = 7.5 HP DDP 80W
G = 7.5 HP DDP 120W
H = 10 HP DDP 80W (60-89T = 2 x 5 HP)
J = 10 HP DDP 120W (60-89T = 2 x 5 HP)
K = 15 HP DDP 80W (60-89T = 2 x 7.5 HP)
L = 15 HP DDP 120W (60-89T = 2 x 7.5 HP)
M = 20 HP DDP 80W (60-89T = 2 x 10 HP)
N = 20 HP DDP 120W (60-89T = 2 x 10 HP)
P = 25 HP DDP 80W
R = 25 HP DDP 120W
T = 30 HP DDP 80W (60-89T = 2 x 15 HP)
U = 30 HP DDP 120W (60-89T = 2 x 15 HP)
V = 40 HP DDP 80W(60-89T = 2 x 20 HP)
W = 40 HP DDP 120W (60-89T = 2 x 20 HP)
X=
50 HP DDP 80W(70 & 75-89T = 2 x 25
HP)
Y=
50 HP DDP 120W (70 & 75-89T = 2 x 25
HP)
Z = 30 HP DDP 100W
(a)
(a)50, 55T only
4=400 RPM F = 1500 RPM
5=
500 RPM G = 1600 RPM
6 = 600 RPM H = 1700 RPM
7 = 700 RPM J = 1800 RPM
8 = 800 RPM K = 1900 RPM
9 = 900 RPM L = 2000 RPM
A = 1000 RPM M = 2100 RPM
B = 1100 RPM N = 2200 RPM
C = 1200 RPM P = 2300 RPM
D = 1300 RPM R = 2400 RPM
E = 1400 RPM
A = No Fresh Air
B = 0-25% Manual
D = 0-100% Economizer
E = 0-100% Economizer w/ TRAQ/DCV
1 = CV - Zone Temp Control
2 = CV - Discharge Temp Control
4 = CV - Zone Temp Control
Space Pressure Control w/ Exhaust/
Return VFD w/o Bypass
5 = CV - Zone Temp Control
Space Pressure Control w/
Exhaust/Return VFD and Bypass
6 = VAV Discharge Temp Control w/ VFD
DIGIT 18 - ZONE SENSOR
Note: *Asterisk indicates current model
number digit A, B, C, etc. These
sensors can be ordered to ship
with the unit.
DIGIT 19 - AMBIENT CONTROL
0=Standard
1=0° Fahrenheit
DIGIT 20 - AGENCY APPROVAL
0=None (cULus Gas Heater, see note)
1=cULus
Note: Includes cULus classified gas
heating section only when second
digit of Model No. is a "F."
DIGITS 21 - 38 -
MISCELLANEOUS
w/o Bypass
7 = VAV Discharge Temp Control w/ VFD
and Bypass
8 = VAV Discharge Temp Control
Supply and Exhaust/Return Fan w/ VFD
w/o Bypass
9 = VAV Discharge Temp Control
Supply and Exhaust/Return Fan
with VFD and Bypass
A = VAV - Single Zone VAV - w/ VFD
w/o Bypass
B = VAV - Single Zone VAV - w/ VFD
and Bypass
C = VAV - Single Zone VAV - Supply and
Exhaust/Return Fan w/ VFD w/o Bypass
D = VAV - Single Zone VAV - Supply and
Exhaust/Return Fan w/ VFD w/ Bypass
0 = None
A = Dual Setpoint Manual or Auto
Changeover (BAYSENS108*)
B = Dual Setpoint Manual or Auto
Changeover w/ System Function
Lights (BAYSENS110*)
C = Room Sensor w/ Override and
Cancel Buttons (BAYSENS073*)
D = Room Sensor w/ Temperature
Adjustment and Override and
Cancel Buttons (BAYSENS074*)
L = Programmable Zone Sensor w/
System Function Lights for
CV, SZVAV, and VAV (BAYSENS119*)
21 A = Unit Disconnect Switch
22 B = Hot Gas Bypass
C=
Hot Gas Reheat w/out Hot Gas
Bypass
D=
Hot Gas Reheat and Hot Gas
Bypass
23 0 = Without Economizer
C = Economizer Control w/
Comparative Enthalpy
Z = Economizer Control w/
Reference Enthalpy
W = Economizer Control w/Dry Bulb
24 E = Low Leak Fresh Air Dampers
25 F = High Duct Temperature
Thermostat
26 G = High Capacity Unit
H = High Efficiency Unit
Tip: EXAMPLE
Model numbers:
SAHL*5040A68A6BD800100W00G0
B000R000800 describes a unit with
the following characteristics:
DX Cooling Only unit w/ no extended
casing, 50 ton nominal cooling
capacity, 460/60/3 power supply,100
percent exhaust with Statitrac, 10 HP
exhaust fan motor with drive
selection No. 8 (800 RPM),
throwaway filters, 20 HP supply fan
motor with drive selection No. B
(1100 RPM), 0-100% economizer w/
dry bulb control, supply and exhaust
VFD w/o bypass, no remote panel,
standard ambient control, cULus
agency approval. High capacity unit,
extended grease lines and spring
isolators.
The service digit for each model
number contains 38 digits; all 38
digits must be referenced.
V = eFlex Variable Speed Compressor
27 0 =
Air-Cooled Aluminum Condenser
Coil
J=
Corrosion Protected Condenser
Coil
A = Evap Condenser
B = Evap Condenser w/ Sump Heater
C=
Evap Condenser w/ Dolphin
WaterCare System
D=
Evap Condenser w/ Sump Heater
and Dolphin WaterCare System
E=
Evap Condenser w/ Conductivity
Controller
F=
Evap Condenser w/ Conductivity
Controller and Sump Heater
28 B = GBAS 0-10V
K = GBAS 0-5V
R = Rapid Restart
29 A =
Motors w/ Internal Shaft
Grounding
30 M = Remote Human Interface
31 N = Ventilation Override Module
32 0 = None
R = Extended Grease Lines
1 = Differential Pressure Gauge
2=
Extended Grease Lines and
Differential Pressure Gauge
33 0 = Standard Panels
T = Access Doors
U = IRU - w/ Std Panels
W = IRU - w/ Access Doors
Y = IRU w/SST - w/ Std Panels
Z = IRU w/SST - w/ Access Doors
34 V = Inter-Processor
Communication Bridge
35 M =
BACnet Communication Interface
(BCI) Module
Y = Trane Communication Interface
(TCI) Module
7 = Trane LonTalk Communication
Interface (LCI) Module
36 8 = Spring Isolators
37 6 = Factory-Powered 15A GFI
Convenience Outlet/Disconnect
Switch
38 A = Supply Fan Piezometer
J = Temperature Sensor
