Unit Replacement
RT-SVX36K-EN 81
Table 36. Approximate Operating Weights, 90-100 Ton, “E” Style Cabinet (Units Built Prior to 1991)
Unit Size/Tons
Rooftop w/o
Exhaust Fans
Rooftop with
Exhaust Fans Curb
SEHE C90 13,150 14,500 600
SFHE C90 13,820 15,150 600
SXHE C90 13,000 14,340 600
SEHE D11 13,700 15,050 600 600
SFHE D11 14,360 15,700 600
SXHE D11 13,550 14,880 600
Figure 50. Perimeter Gasket Material
Figure 51. Typical Partial Perimeter Curb with Pedestal Illustration for 20- 75 Ton Standard Units
