Trane Jupiter JDAC Series User Manual

10
DIRECT EXPANSION UNIT – AIR COOLED
CENTRIFUGAL FANS
Technical characteristics
1) Unit in complete version (including packaging)
2)Nominalairow–Maximumfanpowersupply
4)Minimumairowonlyallowedforunitwithoutelectricalresistances
DIRECT EXPANSION UNIT - WATER COOLED
CENTRIFUGAL FANS
Technical characteristics
1) Unit in complete version (including packaging)
2)Nominalairow–Maximumfanpowersupply
3) Data refer to T
b.s.
=24°C - R.H.=50% T
IN MIX
=30°C T
OUT MIX
=35°C
4)Minimumairowonlyallowedforunitwithoutelectricalresistances
JDAC/JUAC
Model 0115B 0115A 0125B 0125A 0133A 0135A 0150A 0160A
Height mm 1740 1740 1740 1740 1740 1740 1740 1740
Width mm 550 550 550 550 850 850 1200 1200
Depth mm 450 450 450 450 450 450 450 450
Weight
1
kg 140 140 140 140 180 180 220 220
Number of refrigerant
circuits
- 1 1 1 1 1 1 1 1
Number of compressors - 1 -SCROLL 1 -SCROLL 1 -SCROLL 1 -SCROLL 1 -SCROLL 1 -SCROLL 1 -SCROLL 1 -SCROLL
Refrigerant - R410A R410A R410A R410A R410A R410A R410A R410A
Air ow m
3
/h 1626 1626 1731 1731 2977 3301 4482 4482
E.S.P Maximum
2
Pa 116 116 78 78 132 78 20 20
Minimum air ow
4
m
3
/h 1040 1040 1040 1040 1950 1950 3020 3020
Power supply voltage V/ph/Hz 230/1N/50 400/3N/50 230/1N/50 400/3N/50 400/3N/50 400/3N/50 400/3N/50 400/3N/50
JDWC/JUWC
Model 0115B 0115A 0125B 0125A 0133A 0135A 0150A 0160A
Height mm 1740 1740 1740 1740 1740 1740 1740 1740
Depth mm 450 450 450 450 450 450 450 450
Width mm 550 550 550 550 850 850 1200 1200
Weight
1
kg 145 145 145 145 185 185 230 230
Number of refrigerant
circuits
- 1 1 1 1 1 1 1 1
Number of compressors - 1 -SCROLL 1 -SCROLL 1 -SCROLL 1 -SCROLL 1 -SCROLL 1 -SCROLL 1 -SCROLL 1 -SCROLL
Refrigerant - R410A R410A R410A R410A R410A R410A R410A R410A
Air ow m
3
/h 1626 1626 1731 1731 2977 3301 4482 4482
E.S.P Maximum
2
Pa 116 116 78 78 132 78 20 20
Nominal water ow
3
l/h 1355 1350 1740 1705 2152 2746 3586 3912
Minimum air ow
4
m
3
/h 1040 1040 1040 1040 1950 1950 3020 3020
Power supply voltage V/ph/Hz 230/1N/50 400/3N/50 230/1N/50 400/3N/50 400/3N/50 400/3N/50 400/3N/50 400/3N/50
