Trane Jupiter JDAC Series User Manual

7
Installazione
Funzionamento
Manutenzione
Unità ad alta precisione Jupiter
Unità a espansione diretta
JDAC / JUAC / JDAV / JUAV / JDWC / JUWC / JDWV / JUWV
Taglie: 0115 – 0125 – 0133 – 0135 – 0150 – 0160
Unità ad acqua refrigerata
JDCC / JUCC / JDCV / JUCV
Taglie: 0020 – 0025 – 0030 – 0040 – 0060
PKG-SVX24B-IT
AIR FLOW
In the Jupiter conditioners, the air can ow upwards or downwards (UPFLOW / DOWNFLOW)
DOWNFLOW
Downow units (with downwards air discharge) handle
large volumes of air which are distributed uniformly into
the environment by means of a void under a raised access
oor. The air is sucked in through the upper section or the
front section of the unit directly from the environment, or
through a section of conduit connected to the false ceiling
or to ducting.
INTRODUCTION
Presentation of the system
The JUPITER precision air conditioning units are designed for civil use and for all environments characterized by the
presence of equipment with a high technological content: telephone and internet exchanges, data processing centres,
meteorological rooms, laboratories and climate controlled warehouses.
The Jupiter series consists of 2 types of conditioners:
• Direct expansion units
• Chilled water units
DOWNFLOW
UPFLOW
32
4
DOWNFLOW
UPFLOW
32
4
UPFLOW
The Upow air conditioning units (with upwards discharge
of the treated air) are designed for distribution of the air
directly into the environment with or without a discharge
plenum or through a system of ducting or by means of a
false ceiling.
The suction of the air is normally from the front side of the
air conditioner, however, versions are also available with
recovery of the air from the rear of the air conditioner or
from the base support of the unit.

Trane Jupiter JDAC Series Specifications

General

Brand	Trane
Model	Jupiter JDAC Series
Category	Chiller
Language	English
