Trane Jupiter JDAC Series User Manual

11
Installazione
Funzionamento
Manutenzione
Unità ad alta precisione Jupiter
Unità a espansione diretta
JDAC / JUAC / JDAV / JUAV / JDWC / JUWC / JDWV / JUWV
Taglie: 0115 – 0125 – 0133 – 0135 – 0150 – 0160
Unità ad acqua refrigerata
JDCC / JUCC / JDCV / JUCV
Taglie: 0020 – 0025 – 0030 – 0040 – 0060
PKG-SVX24B-IT
DIRECT EXPANSION UNIT – AIR COOLED
RADIAL FANS WITH E.C. TECHNOLOGY
Technical characteristics
1) Unit in complete version (including packaging)
2)Nominalairow–Maximumfanpowersupply
4)Unitwithoutelectricalheaters
DIRECT EXPANSION UNIT - WATER COOLED
RADIAL FANS WITH E.C. TECHNOLOGY
Technical characteristics
1) Unit in complete version (including packaging)
2)Nominalairow–Maximumfanpowersupply
3) Data refer to T
b.s.
=24°C - R.H.=50% T
IN MIX
=30°C T
OUT MIX
=35°C
4)Minimumairowonlyallowedforunitwithoutelectricalresistances
JDAV/JUAV
Model 0115B 0115A 0125B 0125A 0133A 0135A 0150A 0160A
Height mm 1740 1740 1740 1740 1740 1740 1740 1740
Width mm 550 550 550 550 850 850 1200 1200
Depth mm 450 450 450 450 450 450 450 450
Weight
1
kg 132 132 132 132 185 185 260
Number of refrigerant
circuits
- 1 1 1 1 1 1 1 1
Number of compressors - 1 -SCROLL 1 -SCROLL 1 -SCROLL 1 -SCROLL 1 -SCROLL 1 -SCROLL 1 -SCROLL 1 -SCROLL
Refrigerant type - R410A R410A R410A R410A R410A R410A R410A R410A
Nominal air ow m
3
/h 1644 1644 1722 1722 3204 3439 4499 5202
Max. E.S.P
2
Pa 193 193 155 155 178 123 153 40
Minimum air ow
4
m
3
/h 1040 1040 1040 1040 1950 1950 3020 3020
Power supply voltage V/ph/Hz 230/1N/50 400/3N/50 230/1N/50 400/3N/50 400/3N/50 400/3N/50 400/3N/50 400/3N/50
JDWV/JUWV
Model 0115B 0115A 0125B 0125A 0133A 0135A 0150A 0160A
Height mm 1740 1740 1740 1740 1740 1740 1740 1740
Width mm 550 550 550 550 850 850 1200 1200
Depth mm 450 450 450 450 450 450 450 450
Weight 1 kg 132 132 132 132 185 185 260
Number of refrigerant
circuits
- 1 1 1 1 1 1 1 1
Number of compressors - 1 -SCROLL 1 -SCROLL 1 -SCROLL 1 -SCROLL 1 -SCROLL 1 -SCROLL 1 -SCROLL 1 -SCROLL
Refrigerant - R410A R410A R410A R410A R410A R410A R410A R410A
Air ow m
3
/h 1644 1644 1722 1722 3204 3439 4499 5202
E.S.P Maximum
2
Pa 193 193 155 155 178 123 153 40
Nominal water ow
3
1357 1354 1739 1704 2183 2764 3590 4015
Minimum air ow
4
m
3
/h 1040 1040 1040 1040 1950 1950 3020 3020
Power supply voltage V/ph/Hz 230/1N/50 400/3N/50 230/1N/50 400/3N/50 400/3N/50 400/3N/50 400/3N/50 400/3N/50

Trane Jupiter JDAC Series Specifications

General

Brand	Trane
Model	Jupiter JDAC Series
Category	Chiller
Language	English
