Trane Jupiter JDAC Series User Manual

46
Code Description Opening Differential Re-set
TSR
Safety thermostat
(T and H versions)
310 °C
(opening)
-
Manual
reset
TSRA
Safety thermostat
(T and H versions)
328 °C
(opening)
-
Manual
reset
Setting the regulation and safety devices
After starting up the conditioner, set the following set points
(see Microprocessor Control Manual):
• Room temperature (cooling and heating set point);
• Re l ative room h u midity (humidi ficatio n and
dehumidication set point);
• Dirty lter differential pressure switch: see paragraph
“Setting the dirty lter sensor”.
The settings of the safety devices must not be modied.
Maximum available pressure depending on the fan speed regulation:
Allegato Generico
Tabelle
per manuali Amico
ALGC000078
Rev.0
C08003
Pag. 9 / 11
UNITA’ CON VENTILATORI RADIALI
Regolazione nominale del ventilatore (per avere la portata aria nominale con ESP=20Pa)
UNIT WITHOUT ELECTRICAL RESISTANCES UNIT WITH ELECTRICAL RESISTANCES
Rated speed @20Pa Minimum speed @20Pa Rated speed @20Pa Minimum speed @20Pa
Model
EU4 Eu4 +Post EU4 Eu4 +Post EU4 Eu4 +Post EU4 Eu4 +Post
[%] [%] [%] [%] [%] [%] [%] [%]
JDCV
0020
69 70 48 49 69 70 48 49
0025
81 82 42 43 81 82 75 76
0030
83 84 43 43 83 84 76 77
0040
73 75 47 48 74 75 51 52
0060
83 85 53 54 84 87 56 57
JUCV
0020
68 70 48 49 69 70 48 49
0025
81 81 42 43 81 82 75 76
0030
82 83 43 43 83 84 76 77
0040
73 74 47 48 73 75 51 52
0060
100 100 56 57 100 100 60 60
Massima pressione disponibile in funzione della regolazione della velocità del ventilatore:
J*CCV0020*
Air Flow
[m3/h]
1040 1370 1520 1610 1956
Fan speed Discharge stac pressure
[%] [Pa] [Pa] [Pa] [Pa] [Pa]
49 26 - - - -
60 129 20 - - -
69 226 116 57 19 -
80 346 237 178 140 -
85 398 288 229 191 20
J*CV0025*
Air Flow
[m3/h]
1150 1500 1607 2000 2358
Fan speed Discharge stac pressure
[%] [Pa] [Pa] [Pa] [Pa] [Pa]
43 20 - - - -
60 171 86 55 - -
70 279 194 163 23 -
80 389 304 273 133 -
85 440 355 324 184 20
Discharge static pressure
Air Flow
[m
3
/h]
Fan Speed
Allegato Generico
Tabelle
per manuali Amico
ALGC000078
Rev.0
C08003
Pag. 10 / 11
J*CV0030*
Air Flow
[m3/h]
1150 1500 1800 2000 2340
Fan speed Discharge stac pressure
[%] [Pa] [Pa] [Pa] [Pa] [Pa]
44 25 - - - -
60 168 82 - - -
70 276 189 93 16 -
80 386 299 203 126 -
85 437 350 254 177 20
J*CV0040*
Air Flow
[m3/h]
1940 2500 3300 3600 3738
Fan speed Discharge stac pressure
[%] [Pa] [Pa] [Pa] [Pa] [Pa]
48 22 - - - -
60 133 38 - - -
75 296 201 30 - -
80 351 255 84 7 -
85 402 307 135 58 20
J*CV0060*
Air Flow
[m3/h]
3020 3700 4800 5030 5400
Fan speed Discharge stac pressure
[%] [Pa] [Pa] [Pa] [Pa] [Pa]
54 21 - - - -
70 168 95 - - -
82 274 202 51 14 -
90 324 252 102 65 1
100 342 270 120 83 20
CONDENSATORI AD ARIA REMOTI
PAGINA 21
Air Flow
[m
3
/h]
Fan Speed
Discharge static pressure
Allegato Generico
Tabelle
per manuali Amico
ALGC000078
Rev.0
C08003
Pag. 10 / 11
J*CV0030*
Air Flow
[m3/h]
1150 1500 1800 2000 2340
Fan speed Discharge stac pressure
[%] [Pa] [Pa] [Pa] [Pa] [Pa]
44 25 - - - -
60 168 82 - - -
70 276 189 93 16 -
80 386 299 203 126 -
85 437 350 254 177 20
J*CV0040*
Air Flow
[m3/h]
1940 2500 3300 3600 3738
Fan speed Discharge stac pressure
[%] [Pa] [Pa] [Pa] [Pa] [Pa]
48 22 - - - -
60 133 38 - - -
75 296 201 30 - -
80 351 255 84 7 -
85 402 307 135 58 20
J*CV0060*
Air Flow
[m3/h]
3020 3700 4800 5030 5400
Fan speed Discharge stac pressure
[%] [Pa] [Pa] [Pa] [Pa] [Pa]
54 21 - - - -
70 168 95 - - -
82 274 202 51 14 -
90 324 252 102 65 1
100 342 270 120 83 20
CONDENSATORI AD ARIA REMOTI
PAGINA 21
Air Flow
[m
3
/h]
Fan Speed
Discharge static pressure
Allegato Generico
Tabelle
per manuali Amico
ALGC000078
Rev.0
C08003
Pag. 10 / 11
J*CV0030*
Air Flow
[m3/h]
1150 1500 1800 2000 2340
Fan speed Discharge stac pressure
[%] [Pa] [Pa] [Pa] [Pa] [Pa]
44 25 - - - -
60 168 82 - - -
70 276 189 93 16 -
80 386 299 203 126 -
85 437 350 254 177 20
J*CV0040*
Air Flow
[m3/h]
1940 2500 3300 3600 3738
Fan speed Discharge stac pressure
[%] [Pa] [Pa] [Pa] [Pa] [Pa]
48 22 - - - -
60 133 38 - - -
75 296 201 30 - -
80 351 255 84 7 -
85 402 307 135 58 20
J*CV0060*
Air Flow
[m3/h]
3020 3700 4800 5030 5400
Fan speed Discharge stac pressure
[%] [Pa] [Pa] [Pa] [Pa] [Pa]
54 21 - - - -
70 168 95 - - -
82 274 202 51 14 -
90 324 252 102 65 1
100 342 270 120 83 20
CONDENSATORI AD ARIA REMOTI
PAGINA 21
Air Flow
[m
3
/h]
Fan Speed
Discharge static pressure
Allegato Generico
Tabelle
per manuali Amico
ALGC000078
Rev.0
C08003
Pag. 9 / 11
UNITA’ CON VENTILATORI RADIALI
Regolazione nominale del ventilatore (per avere la portata aria nominale con ESP=20Pa)
UNIT WITHOUT ELECTRICAL RESISTANCES UNIT WITH ELECTRICAL RESISTANCES
Rated speed @20Pa Minimum speed @20Pa Rated speed @20Pa Minimum speed @20Pa
Model
EU4 Eu4 +Post EU4 Eu4 +Post EU4 Eu4 +Post EU4 Eu4 +Post
[%] [%] [%] [%] [%] [%] [%] [%]
JDCV
0020
69 70 48 49 69 70 48 49
0025
81 82 42 43 81 82 75 76
0030
83 84 43 43 83 84 76 77
0040
73 75 47 48 74 75 51 52
0060
83 85 53 54 84 87 56 57
JUCV
0020
68 70 48 49 69 70 48 49
0025
81 81 42 43 81 82 75 76
0030
82 83 43 43 83 84 76 77
0040
73 74 47 48 73 75 51 52
0060
100 100 56 57 100 100 60 60
Massima pressione disponibile in funzione della regolazione della velocità del ventilatore:
J*CCV0020*
Air Flow
[m3/h]
1040 1370 1520 1610 1956
Fan speed Discharge stac pressure
[%] [Pa] [Pa] [Pa] [Pa] [Pa]
49 26 - - - -
60 129 20 - - -
69 226 116 57 19 -
80 346 237 178 140 -
85 398 288 229 191 20
J*CV0025*
Air Flow
[m3/h]
1150 1500 1607 2000 2358
Fan speed Discharge stac pressure
[%] [Pa] [Pa] [Pa] [Pa] [Pa]
43 20 - - - -
60 171 86 55 - -
70 279 194 163 23 -
80 389 304 273 133 -
85 440 355 324 184 20
Air Flow
[m
3
/h]
Fan Speed
Discharge static pressure
