Trane Jupiter JDAC Series User Manual

45
Installazione
Funzionamento
Manutenzione
Unità ad alta precisione Jupiter
Unità a espansione diretta
JDAC / JUAC / JDAV / JUAV / JDWC / JUWC / JDWV / JUWV
Taglie: 0115 – 0125 – 0133 – 0135 – 0150 – 0160
Unità ad acqua refrigerata
JDCC / JUCC / JDCV / JUCV
Taglie: 0020 – 0025 – 0030 – 0040 – 0060
PKG-SVX24B-IT
RADIAL FANS WITH E.C. TECHNOLOGY
Nominal fan regulation (to have the nominal airow with ESP=20Pa
Allegato Generico
Tabelle
per manuali Amico
ALGC000078
Rev.0
C08003
Pag. 8 / 11
J*CC0030*
Air Flow
[m3/h]
1150 1500 2000 2300 2339
Fan Speed Discharge stac pressure
[%] [Pa] [Pa] [Pa] [Pa] [Pa]
53 27 - - - -
60 146 - - - -
80 203 200 71 - -
90 188 198 124 11 -
100 228 208 130 36 20
J*CC0040*
Air Flow
[m3/h]
1940 2500 3000 3360 3470
Fan Speed Discharge stac pressure
[%] [Pa] [Pa] [Pa] [Pa] [Pa]
47 26 - - - -
60 200 49 - - -
70 232 145 5 - -
90 235 168 100 27 -
100 299 190 111 44 20
J*CC0060*
Air Flow
[m3/h]
3020 3500 4000 4200 4488
Fan Speed Discharge stac pressure
[%] [Pa] [Pa] [Pa] [Pa] [Pa]
62 14 - - - -
70 131 33 - - -
80 181 133 41 - -
90 179 153 94 60 -
100 189 155 100 71 20
Allegato Generico
Tabelle
per manuali Amico
ALGC000078
Rev.0
C08003
Pag. 9 / 11
UNITA’ CON VENTILATORI RADIALI
Regolazione nominale del ventilatore (per avere la portata aria nominale con ESP=20Pa)
UNIT WITHOUT ELECTRICAL RESISTANCES UNIT WITH ELECTRICAL RESISTANCES
Rated speed @20Pa Minimum speed @20Pa Rated speed @20Pa Minimum speed @20Pa
Model
EU4 Eu4 +Post EU4 Eu4 +Post EU4 Eu4 +Post EU4 Eu4 +Post
[%] [%] [%] [%] [%] [%] [%] [%]
JDCV
0020
69 70 48 49 69 70 48 49
0025
81 82 42 43 81 82 75 76
0030
83 84 43 43 83 84 76 77
0040
73 75 47 48 74 75 51 52
0060
83 85 53 54 84 87 56 57
JUCV
0020
68 70 48 49 69 70 48 49
0025
81 81 42 43 81 82 75 76
0030
82 83 43 43 83 84 76 77
0040
73 74 47 48 73 75 51 52
0060
100 100 56 57 100 100 60 60
Massima pressione disponibile in funzione della regolazione della velocità del ventilatore:
J*CCV0020*
Air Flow
[m3/h]
1040 1370 1520 1610 1956
Fan speed Discharge stac pressure
[%] [Pa] [Pa] [Pa] [Pa] [Pa]
49 26 - - - -
60 129 20 - - -
69 226 116 57 19 -
80 346 237 178 140 -
85 398 288 229 191 20
J*CV0025*
Air Flow
[m3/h]
1150 1500 1607 2000 2358
Fan speed Discharge stac pressure
[%] [Pa] [Pa] [Pa] [Pa] [Pa]
43 20 - - - -
60 171 86 55 - -
70 279 194 163 23 -
80 389 304 273 133 -
85 440 355 324 184 20
UNIT WITHOUT ELECTRICAL HEATERS
Nominal speed @20Pa Nominal speed @20Pa
Discharge static pressure
Air Flow
[m
3
/h]
Air Flow
[m
3
/h]
Air Flow
[m
3
/h]
Fan Speed
Fan Speed
Fan Speed
Discharge static pressure
Discharge static pressure
Minimum speed @20PaMinimum speed @20Pa
Model
UNIT WITH ELECTRICAL HEATERS
