Trane Jupiter JDAC Series User Manual

37
Installazione
Funzionamento
Manutenzione
Unità ad alta precisione Jupiter
Unità a espansione diretta
JDAC / JUAC / JDAV / JUAV / JDWC / JUWC / JDWV / JUWV
Taglie: 0115 – 0125 – 0133 – 0135 – 0150 – 0160
Unità ad acqua refrigerata
JDCC / JUCC / JDCV / JUCV
Taglie: 0020 – 0025 – 0030 – 0040 – 0060
PKG-SVX24B-IT
G - Chilled water valve
• G1 Servomotor
• G2 Manual control knob
H1:cold water inlet valve
H2: cold water outlet valve
E - Air Filter
Filter the air released into the environment
F - Fans
Allow the diffusion of air into the room
• F1 Fan speed regulator
D - Electric panel
• D1 Magnetothermic
- auxiliary
- heater (optional)
- humidi er (optional)
- fans
• D2 Interface board
• D3 Dirty  lter sensor
• D4 Air  ow sensor
• D5 Main switch
• D6 Terminal board
• D7
a Input/output electrical supply cables
• D7b Input/output electrical auxiliary cables
• D7c Input/output signal cables (RS485 and/or LAN)
G1
G2
D5
D1
D2
D3
D6
D 7a
I
D 7b
D 7c
D 7d
F1
F
D8
E
F
E
G
G1
G
H2
H1
