Trane Jupiter JDAC Series User Manual

5
Installazione
Funzionamento
Manutenzione
Unità ad alta precisione Jupiter
Unità a espansione diretta
JDAC / JUAC / JDAV / JUAV / JDWC / JUWC / JDWV / JUWV
Taglie: 0115 – 0125 – 0133 – 0135 – 0150 – 0160
Unità ad acqua refrigerata
JDCC / JUCC / JDCV / JUCV
Taglie: 0020 – 0025 – 0030 – 0040 – 0060
PKG-SVX24B-IT
• AIR FILTERS
Remove the air lters.
- Materials: metallic net, synthetic bre.
• FINNED COIL
Remove the nned coils from the machine.
- Materials: copper, aluminium, steel.
• HUMIDIFIER
If a humidier is installed, remove it.
- Materials: polypropylene, iron materials.
• ELECTRO-MECHANICAL PARTS
Find and remove valves, electro-mechanical and
electronic parts (three-way valves, sensors, etc.) from
the machine.
• RESISTANCES
Remove the resistances if they are installed.
- Materials: aluminium, inseparable copper + magnesium
oxide.
• PIPES AND PARTS OF THE REFRIGERATING
CIRCUIT
Find the connection pipes installed in the machine and
separate them from the other elements.
Pipes can be caulked: in this case, before recovery,
separate the insulating material from the metal pipe.
Even the elements of the refrigerating circuit are
considered as pipes: joints or valves.
- Materials: copper, brass, cast iron, steel and plastic.
• PUMP
Remove the pump from the machine.
- Materials: pump.
• CONDENSER
Remove the condenser, if installed.
The condenser contains the elements of a machine,
equipped with a small electrical panel, fans and a
thermal exchange battery, usually characterized
by aluminium structure and feet made of varnished
steel.
- Materials: electrical elements, aluminium, steel
(varnished).
• BRAZED PLATE EXCHANGER
If installed, remove the brazed plate exchanger.
- Materials: INOX AISI braze welding, with an alloy
containing a large amount of silver.
• FANS
Remove the fans. Disassemble the metal frame and
proceed with the recycling of the metal alloy.
- Materials: electro-mechanical elements, iron
wrecks.
WARNING! The fans of some machine models are
integral part of the carrying structure. Removing
the fans can compromise the stability of the
frame. We recommend to pay attention during
disassembling operations.
• COMPRESSORS AND LIQUID SEPARATORS
WARNING! Pay attention to oil contained in
the compressors. Avoid any loss of oil during
operations. If possible, dispose of oil and
compressors separately.
Finally remove the liquid separators and the compressors
from the machine base.
- Materials: liquid separators and compressors
• METAL BASE
Proceed with the recycling of the metal base.
- Materials: galvanised sheet.
WARNING! Waste deriving from machine
disassembly must be disposed of and classied
according to CER codes only consulting
authorised and specialist companies.
The following chart contains a partial list of the typical CER
codes applied to waste deriving from disassembling, so it
must be considered just as an indication.
ELEMENTS CER 2002 CODES
Electrical cables 17 04 11
Plastic materials 16 01 19
Metal supports 16 01 17
Galvanised sheet 17 04 07
Aluminium 17 04 02
Metallic net 17 04 05
Synthetic bre 15 02 03
Copper 17 04 01
Brass 17 04 01
Cast iron 17 04 05
Steel 17 04 07
Refrigerating gas 14 06 01
Battery 16 06 04
Pumps, electro-mechanical
elements, compressors
17 09 04
