General Information
RTHD-SVX02H-EN 13
Figure 3. Component Location for Typical RTHD Unit (Back View)
Oil Separators
EXVs
Relief Valves
Service Valves
(With Refrigerant Isolation
Valve Option Only)
Oil Sump
(The oil distribution system is located between
the condenser and the evaporator.)
Condenser
Evaporator
Water Inlet
Unit Nameplate
(On side of starter/control pa
ne
Compressor
Discharge Line
Oil Filter (Cold)
Hot Oil Filter is
hidden from view.
