General Information
14 RTHD-SVX02H-EN
Figure 4. Component Location for Typical RTHD Total Heat Reclaim Unit
TD7 Interface
Oil Separator
Relief Valves
Oil Sump
Starter/Control Panel
Evaporator
Liquid Level Sensor
Gas Pump
Evaporator Water Outlet
