Trane RTHD series User Manual

General Information
RTHD-SVX02H-EN 15
Figure 5. Component Location for Typical RTHD Total Heat Reclaim Unit (Back View)
Oil Separator
Compressor
Unit Nameplate
(On side of starter/
control pane
Discharge Line
Evaporator
Water Inlet
Standard Condenser
Water Inlet
Total Heat Reclaim
Condenser Water Inlet
Total Heat Reclaim
Condenser Water Outlet
Oil Sump (The oil distribution
system is located between the
condenser and the evaporator.)
Service Valves (With Refrigerant
Isolation Valve Option Only)
Standard Condenser
Water Outlet
EXVs
Relief Valves
Oil Filter (Cold)
Hot Oil Filter is hidden
from view.
Standard/Total
Heat Reclaim
Condenser
