Trane RTHD series User Manual

Installation Mechanical
36 RTHD-SVX02H-EN
Figure 13. Condenser and Evaporator Water Connections -BBB
24.48 [622 mm]
12 . 47 [317 mm]
11.50 [292 mm]
13.35 [339 mm]
9.50 [241 mm]
70.30 [1786 mm]
13.84 [351 mm]
9.44 [240 mm]
107.66 [2734 mm]
Standard 3 Pass
28.59 [726 mm]
9.44 [240 mm]
72.80 [1849 mm]
7.80[198 mm]
97.51 [2477 mm]
4.96 [1 26 mm]
0.08 [2 mm]
10.23 [260 mm]
O UT
IN
IN
COND
EV AP
CONDENSER
OIL S UMP
IN
OUT
EVAPORATOR
EV A POR ATO R
2 Pass Evaporator
Connection Configuration (left or right hand)
Depends on Water Inlet
28.46 [723 mm]
1
3.90 [353 mm]
10.31 [262 mm]
6.97 [177 mm]
64.34 [1634 mm]
