Trane RTHD series User Manual

Installation Mechanical
RTHD-SVX02H-EN 37
Figure 14. Condenser and Evaporator Water Connections -BCD/CCD
24.48 [622 mm]
12.47[317 mm]
11.50 [292 mm]
13.35 [339 mm]
9.50 [241 mm]
13.84 [351 mm]
9.44 [240 mm]
125.91 [3198 mm]
St an da r d 3 Pa ss
9.44 [240 m m]
28.59 [726 mm]
7 0. 80 [ 1798 m m]
11 8. 00 [ 2997 mm]
7.80 [198] mm
7.91 [201 mm]
0 .0 1 [ 0 mm]
COND
EV AP
IN
O UT
IN
EVAPORATOR
CONDENSER
OIL SUM P
IN
4. 96 [ 12 6 m m]
OUT
72.80 [1849 mm]
EVAPORATOR
2 Pass Evaporator
Connection Configuration (left or right hand)
Depends on Water Inlet
28.46 [723 mm]
13.90[353 mm]
10.31 [262 mm]
6.97 [177 mm]
66.74 [1695 mm]
