Installation Mechanical
38 RTHD-SVX02H-EN
Figure 15. Condenser and Evaporator Water Connections - CEF
27.22[692 m m]
12.73 [323 mm]
12.49 [317 mm]
67.5 4 [17 15 mm]
14.50 [368 mm]
5.29 [134 mm]
73.44 [1865 mm]
14.88 [378 mm]
10.20 [260 mm]
125. 9 1 [31 98 mm]
Standard 3 Pass
30.1 3 [76 5 mm ]
10.20 [260m m]
76. 2 4 [19 37 mm]
4.84 [123 mm]
3.07 [78 mm]
6.0 0 [15 3 mm ]
9.11 [232 mm]
118.00 [2997 mm]
OUT
IN
IN
OUT
EVAPORATOR
OI L SUMP
CONDENSER
IN
COND EV AP
EVAPORATOR
2 Pass Evaporator
Connection Configuration (left or right hand)
Depends on Water Inlet
7.67 [195 mm]
29.80 [757 mm]
15.24 [387 mm]
11.02[280 mm]
