Trane RTHD series User Manual

Installation Mechanical
40 RTHD-SVX02H-EN
Figure 17. Condenser and Evaporator Water Connections – CFF/DFF/EFF
27.22 [692 mm]
12.49 [317 mm]
67.54 [1 71 6 mm ]
16.2 0 [41 1 mm ]
3.59 [91 mm]
73.5 2 [18 67 m m]
10.91 [277 mm]
10.67 [271 mm]
125.91 [3198 mm]
Standar d 3 P ass
27.91 [709 mm]
10.67 [271 mm]
12.73 [323 mm]
4.87 [124 mm] 3.0 4 [77 m m]
6.00 [153 mm]
9.11 [232mm ]
118.00 [2997 mm]
76.23 [1936 mm]
OUT
IN
IN
COND
EV AP
IN
EVAPORATOR
OU T
OIL S UMP
CONDENSER
EVAPORATOR
2 Pass Evaporator
Connection Configuration (left or right hand)
Depends on Water Inlet
27.87 [708mm]
10.94 [278 mm]
12.52 [318 mm]
8.71 [221 mm]
