Installation Mechanical
RTHD-SVX02H-EN 41
Figure 18. Condenser and Evaporator Water Connections - CGG/DGG/EGG
69.72 [1771 mm]
14.70 [373 mm]
1.18 [30 mm]
18.63 [473 mm]
9.35 [238 mm]
125.91 [3198 mm]
Standard 4 Pass
33.89 [861 mm]
12.20 [310 mm]
10.35[263 mm]
129.80 [3297 mm]
7.
28 [185 mm]
0.67 [17 mm]
3.22 [82 mm]
77.29 [1963 mm]
80.02 [2033 mm]
OUT
IN
COND
EVAP
OUT
IN
EVAPORATOR
CONDENSER
O IL SUMP
22.50 [571 mm]
2 9. 09 [739 m m]
14.61 [371mm]
IN
OUT
11.39 [289 mm]
EVAPORATOR
3 Pass Evaporator
Connection Configuration (left or right hand)
Depends on Water Inlet
CONFORMS TO ASME Y14.5M-1994
ANGLES =
HOLE DIA =
+
-
12.60 [320 mm]
14.17 [360 mm]
32.64 [829 mm]
14.17 [360 mm]
