Installation Mechanical
42 RTHD-SVX02H-EN
Figure 19. Condenser and Evaporator Water Connections - BCH
75.55 [191
9 mm]
28.59 [726 mm]
9.44 [240 mm]125.91 [3198 mm]
Standard 3 -pass
13.84 [351 mm]
9.44 [240 mm]
70.80 [1798 mm]
9.50 [241 mm]13.35 [339 mm]
72.05 [1830 mm]
10.16 [258 mm]
22.52 [572 mm]
14.25 [362 mm]
26.30
[668 mm]
IN
OUTOUT
OUT
IN
IN
COND
EVAP
8.27 [210 mm]118.00 [2997 mm]14.43 [367 mm]
21.93 [557 mm]
7.91 [201 mm] 0.01 [0 mm]
Condenser
Evaporator
Evaporator
Oil Sump
