18
RLC-SVX09Q-EN
Table 6. RTWD, 80 to 140 tons, 60 Hz – in (mm)
Standard Efficiency RTWD - High Efficiency
80,90T 100,110T 120,130,140T 80,90T 100,110,120,130T
A (2 pass evap) 138.2 (3510) 138.2 (3510) 138.8 (3525) 126.4 (3210) 126.9 (3225)
B (3 pass evap) 142.6 (3621) 142.6 (3621) 142.6 (3621) 130.8 (3321) 130.7 (3320)
C
75.9 (1929) 76.9 (1955) 76.9 (1955) 76.1 (1933) 76.9 (1955)
D
34.3 (871) 34.3 (871) 34.8 (884) 35.1 (890) 35.1 (890)
E
23.6 (600) 23.6 (600) 23.6 (600) 23.6 (600) 23.6 (600)
F
9.1 (231) 9.1 (231) 9.1 (231) 9.1 (231) 9.1 (231)
G
27.9 (709) 27.9 (709) 27.9 (709) 27.9 (709) 27.9 (709)
H
36.6 (929) 36.6 (929) 36.6 (929) 36.6 (929) 36.6 (929)
J (2 pass evap) 11.0 (280) 11.0 (280) 10.6 (268) 10.8 (273) 11.8 (299)
J (3 pass evap) 10.4 (265) 10.4 (265) 10.1 (256) 10.2 (258) 11.3 (287)
K (2 pass evap) 18.9 (479) 18.9 (479) 19.2 (487) 18.6 (472) 20.4 (519)
L (3 pass evap) 19.5 (495) 19.5 (495) 19.5 (496) 19.2 (488) 19.2 (487)
M
36 (914) 36 (914) 36 (914) 36 (914) 36 (914)
N*
36 (914)* 36 (914)* 36 (914)* 36 (914)* 36 (914)*
R
127 (3226) 127 (3226) 127 (3226) 115 (2921) 115 (2921)
S
36 (914) 36 (914) 36 (914) 36 (914) 36 (914)
Reference
Notes:
1. Evaporator Water Inlet
2. Evaporator Water Outlet
3. Condenser Water Inlet
4. Condenser Water Outlet
5. Power Disconnect
6. Power Wire
7. Control Wire
8. Control Panel
9. Condenser Return Waterbox End - minimum clearance (for tube removal)
10. Condenser Supply Waterbox End - minimum clearance (for maintenance)
11. Condenser
12. Evaporator
13. Panel Power Section - door swing 31.3 inch (796.9 mm)
14. Panel Power Section - door swing 31.1 inch (790.1 mm)
15. Panel Control Section - door swing 22.4 inch (568.14 mm)
16. 42 inch (1067 mm) clearance required to other ground parts, two units with panels facing each other or other live parts require
a clearance of 48 inch (1220 mm)
17. Sound attenuator may increase the footprint - submittal should be used.
Unit Dimensions and Weights
