20
RLC-SVX09Q-EN
Table 7. RTWD, 150 to 250 tons, 60 Hz – in (mm)
RTWD
High Efficiency Prem Efficiency
150-200T
220, 250T
150-200T
A (2 pass evap) 132.3 (3360) 136.1 (3456) 147.9 (3755)
B (3 pass evap) 132.8 (3371) 136.1 (3456) 150.9 (3831)
C
75.6 (1920) 76.9 (1955) 76.8 (1950)
D
47.3 (1202) 47.8 (1213) 47.3 (1202)
E
24.6 (624) 24.8 (630) 24.6 (624)
F
11.1 (282) 11.2 (295) 11.1 (282)
G
32.7 (830) 33.1 (840) 33.8 (860)
H
42.4 (1078) 43.9 (1115) 43.6 (1108)
J (2 pass evap) 10.1 (256) 10.6 (270) 10.6 (270)
J (3 pass evap) 9.5 (241) 9.7 (247) 9.7 (247)
K (2 pass evap) 19.3 (490) 20.6 (524) 20.6 (524)
L (3 pass evap) 19.9 (505) 21.6 (549) 21.6 (549)
M
36.0 (914) 36.0 (914) 36.0 (914)
N
36.0 (914) 36.0 (914) 36.0 (914)
P*
40 (1016)* 40 (1016)* 40 (1016)*
R
114.8 (2916) 114.8 (2916) 134.5 (3416)
S
36.0 (914) 36.0 (914) 36.0 (914)
Reference
Notes:
1. Evaporator Water Inlet
2. Evaporator Water Outlet
3. Condenser Water Inlet
4. Condenser Water Outlet
5. Power Disconnect
6. Power Wire
7. Control Wire
8. Control Panel
9. Condenser Return Waterbox End - minimum clearance (for tube removal)
10. Condenser Supply Waterbox End - minimum clearance (for maintenance)
11. Condenser
12. Evaporator
13. Panel Power Section - door swing 31.3 inch (796.9 mm)
14. Panel Power Section - door swing 31.1 inch (790.1 mm)
15. Panel Control Section - door swing 22.4 inch (568.14 mm)
16. Control panel clearance is 36 or 40 inch (914 or 1016 mm) depending on voltages, starter
type, unit application and local
code; 42 inch (1067 mm) clearance required to other grounded parts; two units with panels
facing each other or other
live parts require a clearance of 48 inch (1220 mm).
17. Sound attenuator may increase the footprint - submittal should be used.
Unit Dimensions and Weights
