Table 13. S9V2B080U4PSC / S9V2B080D4PSC Cooling Airflow (continued)
S9V2B080U4PSC / S9V2B080D4PSC Furnace Cooling Airflow (CFM) and Power (Watts) vs. External Static Pressure with
Filter
Cooling
Unit
Outdoor
Airflow
Setting
(CFM/ton)
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Cooling
3.0 Ton
Cooling 450
CFM/Ton
CFM 1326 1341 1341 1325 1296
Watts 257 320 380 439 497
Cooling 420
CFM/Ton
CFM 1239 1252 1250 1234 1203
Watts 214 273 330 385 440
Cooling 400
CFM/Ton
CFM 1181 1193 1191 1173 1142
Watts 188 245 299 353 405
Cooling 370
CFM/Ton
CFM 1094 1105 1101 1083 1050
Watts 153 207 258 308 358
Cooling 350
CFM/Ton
CFM 1036 1046 1041 1022 989
Watts 133 184 233 281 329
Cooling 330
CFM/Ton
CFM 978 987 982 962 928
Watts 115 164 210 256 302
Cooling 310
CFM/Ton
CFM 920 929 923 902 868
Watts 99 145 189 233 277
Cooling 290
CFM/Ton
CFM 863 870 863 843 807
Watts 84 128 170 212 253
Cooling
3.5 Ton
Cooling 450
CFM/Ton
CFM 1547 1565 1568 1556 1529
Watts 392 463 531 598 664
Cooling 420
CFM/Ton
CFM 1443 1460 1462 1448 1420
Watts 324 391 456 519 581
Cooling 400
CFM/Ton
CFM 1375 1391 1391 1376 1347
Watts 284 348 410 471 530
Cooling 370
CFM/Ton
CFM 1273 1287 1286 1269 1239
Watts 230 290 349 405 461
Cooling 350
CFM/Ton
CFM 1205 1218 1215 1199 1167
Watts 198 256 312 366 420
Cooling 330
CFM/Ton
CFM 1137 1149 1146 1128 1096
Watts 170 225 278 330 381
Cooling 310
CFM/Ton
CFM 1069 1080 1076 1057 1024
Watts 145 197 248 297 345
Cooling 290
CFM/Ton
CFM 1002 1012 1007 987 954
Watts 122 172 220 266 313
Cooling
4.0 Ton
(a)
Cooling 450
CFM/Ton
CFM 1769 1791 1797 1789 1766
Watts 570 648 725 799 873
Cooling 420
CFM/Ton
CFM 1650 1670 1675 1664 1639
Watts 469 544 616 686 756
Cooling 400
CFM/Ton
CFM 1571 1590 1593 1582 1555
Watts 410 481 550 618 685
Cooling 370
CFM/Ton
CFM 1453 1470 1472 1458 1430
Watts 330 397 462 526 588
Cooling 350
CFM/Ton
(a)
CFM 1375 1391 1391 1376 1347
Watts 284 348 410 471 530
Cooling 330
CFM/Ton
CFM 1297 1312 1311 1295 1265
Watts 242 303 363 420 477
Cooling 310
CFM/Ton
CFM 1219 1233 1230 1214 1183
Watts 205 263 319 374 428
Cooling 290
CFM/Ton
CFM 1142 1154 1151 1133 1101
Watts 172 227 280 332 384
(a)
Factory Setting.
