Table 14. S9V2C080U5PSC Heating Airflow
S9V2C080U5PSC Furnace Heating Airflow (CFM), Temp. Rise (°F), and Power (Watts) vs. External Static Pressure with
Filter (iwc)
1st Stage Capacity = 50,600
2nd Stage Capacity = 77,750
Heating
Airflow
Setting
Target
Airflow
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Heating 1st
Stage
Low 857
CFM 838 821 804 788 771
Temp. Rise
56 57 57 58 59
Watts 68 109 151 192 234
Medium Low
(a)
1044
CFM 967 993 1019 1045 1070
Temp. Rise
48 47 46 45 44
Watts 91 145 198 252 306
Medium 1123
CFM 1060 1058 1056 1053 1051
Temp. Rise
44 44 44 43 43
Watts 108 165 222 279 335
High
1224
CFM 1266 1171 1075 980 884
Temp. Rise
36 40 43 46 50
Watts 134 194 253 313 373
Heating 2nd
Stage
Low 1190
CFM 1114 1127 1141 1154 1167
Temp. Rise
64 63 62 62 61
Watts 127 188 250 312 373
Medium Low
(a)
1450
CFM 1359 1378 1396 1414 1432
Temp. Rise
52 52 51 50 49
Watts 216 291 365 439 514
Medium 1560
CFM 1466 1474 1482 1490 1497
Temp. Rise
48 48 48 48 48
Watts 263 344 426 507 588
High
1700
CFM 1774 1731 1689 1647 1605
Temp. Rise
40 41 42 43 44
Watts 356 437 518 600 681
(a)
Factory Setting.
Table 15. S9V2C080U5PSC Cooling Airflow
S9V2C080U5PSC Furnace Cooling Airflow (CFM) and Power (Watts) vs. External Static Pressure with Filter (iwc)
Cooling
Unit
Outdoor
Airflow
Setting
(CFM/ton)
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Cooling
3.0 Ton
Cooling 450
CFM/Ton
CFM 1335 1347 1356 1362 1366
Watts 182 241 303 366 431
Cooling 420
CFM/Ton
CFM 1246 1259 1267 1273 1277
Watts 152 208 266 326 387
Cooling 400
CFM/Ton
CFM 1188 1200 1208 1214 1217
Watts 134 188 243 301 360
Cooling 370
CFM/Ton
CFM 1100 1111 1118 1123 1125
Watts 110 160 212 266 322
Cooling 350
CFM/Ton
CFM 1041 1052 1058 1061 1063
Watts 96 143 193 245 299
Cooling 330
CFM/Ton
CFM 983 993 997 999 1000
Watts 83 128 176 225 277
Cooling 310
CFM/Ton
CFM 925 933 936 937 936
Watts 72 114 159 207 257
Cooling 290
CFM/Ton
CFM 867 873 874 873 871
Watts 61 101 144 190 239
Cooling
3.5 Ton
Cooling 450
CFM/Ton
CFM 1557 1568 1576 1581 1585
Watts 273 342 413 486 559
Cooling 420
CFM/Ton
CFM 1453 1465 1473 1480 1483
Watts 228 292 359 427 496
Cooling 400
CFM/Ton
CFM 1384 1396 1405 1411 1415
Watts 200 262 325 391 457
Cooling 370
CFM/Ton
CFM 1281 1293 1302 1308 1312
Watts 163 221 280 341 404
Cooling 350
CFM/Ton
CFM 1212 1224 1233 1239 1242
Watts 142 196 253 311 371
Cooling 330
CFM/Ton
CFM 1144 1155 1163 1168 1171
Watts 122 173 227 283 341
Cooling 310
CFM/Ton
CFM 1076 1086 1093 1097 1099
Watts 104 153 204 257 312
Cooling 290
CFM/Ton
CFM 1007 1017 1023 1025 1026
Watts 88 134 183 233 286
