Table 15. S9V2C080U5PSC Cooling Airflow (continued)
S9V2C080U5PSC Furnace Cooling Airflow (CFM) and Power (Watts) vs. External Static Pressure with Filter (iwc)
Cooling
Unit
Outdoor
Airflow
Setting
(CFM/ton)
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Cooling
4.0 Ton
Cooling 450
CFM/Ton
CFM 1782 1789 1794 1797 1798
Watts 392 471 551 632 715
Cooling 420
CFM/Ton
CFM 1662 1671 1678 1682 1685
Watts 325 399 474 550 628
Cooling 400
CFM/Ton
CFM 1582 1592 1600 1606 1609
Watts 285 355 427 500 575
Cooling 370
CFM/Ton
CFM 1463 1474 1483 1489 1493
Watts 232 297 364 432 502
Cooling 350
CFM/Ton
CFM 1384 1396 1405 1411 1415
Watts 200 262 325 391 457
Cooling 330
CFM/Ton
CFM 1305 1317 1327 1333 1337
Watts 172 230 290 352 416
Cooling 310
CFM/Ton
CFM 1227 1239 1248 1254 1257
Watts 146 201 258 317 378
Cooling 290
CFM/Ton
CFM 1149 1160 1168 1173 1176
Watts 123 175 229 285 343
Cooling
4.5 Ton
Cooling 450
CFM/Ton
CFM 2008 2011 2012 2011 2008
Watts 542 630 719 811 903
Cooling 420
CFM/Ton
CFM 1872 1878 1881 1883 1882
Watts 448 530 614 700 786
Cooling 400
CFM/Ton
CFM 1782 1789 1794 1797 1798
Watts 392 471 551 632 715
Cooling 370
CFM/Ton
CFM 1647 1656 1663 1668 1670
Watts 318 390 465 541 618
Cooling 350
CFM/Ton
CFM 1557 1568 1576 1581 1585
Watts 273 342 413 486 559
Cooling 330
CFM/Ton
CFM 1468 1479 1488 1494 1498
Watts 234 299 366 435 505
Cooling 310
CFM/Ton
CFM 1379 1391 1400 1407 1410
Watts 198 260 323 388 455
Cooling 290
CFM/Ton
CFM 1291 1303 1312 1318 1322
Watts 167 224 284 346 409
Cooling
5.0 Ton
(a)
Cooling 450
CFM/Ton
CFM 2235 2233 2230 2224 2216
Watts 726 824 923 1023 1125
Cooling 420
CFM/Ton
CFM 2084 2085 2084 2082 2078
Watts 599 690 783 877 973
Cooling 400
CFM/Ton
CFM 1983 1986 1988 1988 1985
Watts 524 611 699 789 880
Cooling 370
CFM/Ton
CFM 1832 1838 1843 1845 1845
Watts 423 503 586 669 754
Cooling 350
CFM/Ton
(a)
CFM 1732 1740 1746 1749 1751
Watts 363 440 518 597 678
Cooling 330
CFM/Ton
CFM 1632 1641 1649 1654 1656
Watts 310 382 456 531 608
Cooling 310
CFM/Ton
CFM 1533 1543 1551 1557 1561
Watts 262 330 400 471 544
Cooling 290
CFM/Ton
CFM 1434 1445 1454 1460 1464
Watts 219 283 349 416 485
(a)
Factory Setting.
