Table 16. S9V2C100U5PSC Heating Airflow
S9V2C100U5PSC Furnace Heating Airflow (CFM), Temp. Rise (°F), and Power (Watts) vs. External Static Pressure with
Filter (iwc)
1st Stage Capacity = 63,400
2nd Stage Capacity = 97,650
Heating
Airflow
Setting
Target
Airflow
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Heating 1st
Stage
Low 1145
CFM 1111 1097 1083 1068 1054
Temp. Rise
52 52 52 52 53
Watts 135 184 234 283 333
Medium Low 1426
CFM 1393 1383 1372 1362 1352
Temp. Rise
41 41 42 42 42
Watts 232 286 340 394 447
Medium
(a)
1483
CFM 1451 1447 1443 1438 1434
Temp. Rise
39 40 40 40 40
Watts 260 310 360 410 460
High
1548
CFM 1495 1477 1458 1439 1421
Temp. Rise
38 39 39 40 40
Watts 285 352 419 486 553
Heating 2nd
Stage
Low 1590
CFM 1564 1550 1536 1522 1508
Temp. Rise
58 58 58 58 59
Watts 323 397 470 544 618
Medium Low 1980
CFM 1959 1936 1913 1891 1868
Temp. Rise
46 46 47 47 47
Watts 597 681 764 847 930
Medium
(a)
2060
CFM 2047 2034 2021 2008 1995
Temp. Rise
44 44 44 45 45
Watts 655 737 818 900 982
High
2150
CFM 2102 2087 2073 2058 2044
Temp. Rise
43 43 43 44 44
Watts 745 801 857 913 969
(a)
Factory Setting.
Table 17. S9V2C100D5PSC Heating Airflow
S9V2C100D5PSC Furnace Heating Airflow (CFM), Temp. Rise (°F), and Power (Watts) vs. External Static Pressure with
Filter (iwc)
1st Stage Capacity = 63,300
2nd Stage Capacity = 97,150
Heating
Airflow
Setting
Target
Airflow
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Heating 1st
Stage
Low 1094
CFM 1093 1092 1090 1089 1088
Temp. Rise
53 53 53 52 52
Watts 126 183 240 296 353
Medium Low 1296
CFM 1234 1238 1242 1247 1251
Temp. Rise
47 47 47 47 47
Watts 186 243 299 356 413
Medium
(a)
1346
CFM 1279 1268 1256 1245 1234
Temp. Rise
45 45 46 46 47
Watts 214 268 321 375 428
High
1512
CFM 1453 1429 1405 1381 1358
Temp. Rise
40 40 41 41 42
Watts 277 344 411 478 545
Heating 2nd
Stage
Low 1520
CFM 1484 1477 1469 1461 1453
Temp. Rise
60 60 61 61 61
Watts 296 370 444 518 592
Medium Low 1800
CFM 1693 1688 1684 1679 1674
Temp. Rise
53 53 53 53 53
Watts 449 533 618 702 786
Medium
(a)
1870
CFM 1768 1772 1775 1778 1781
Temp. Rise
51 50 50 50 50
Watts 505 591 678 765 852
High
2100
CFM 1969 1956 1944 1931 1918
Temp. Rise
45 45 46 46 46
Watts 723 789 854 920 986
(a)
Factory Setting.
