30
S9V2-SVX001-1B-EN
Table 18. S9V2C100U5PSC / S9V2C100D5PSC Cooling Airflow (continued)
S9V2C100U5PSC / S9V2C100D5PSC Furnace Cooling Airflow (CFM) and Power (Watts) vs. External Static Pressure with
Filter (iwc)
Cooling
Unit Outdoor
Airflow
Setting
(CFM/ton)
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Cooling
4.5 Ton
Cooling 450
CFM/Ton
CFM 2037 2034 2031 2026 2020
Watts 537 621 706 792 879
Cooling 420
CFM/Ton
CFM 1907 1905 1902 1898 1893
Watts 444 522 601 682 763
Cooling 400
CFM/Ton
CFM 1820 1819 1816 1812 1807
Watts 388 462 538 615 693
Cooling 370
CFM/Ton
CFM 1689 1687 1685 1682 1677
Watts 313 382 452 524 597
Cooling 350
CFM/Ton
CFM 1601 1599 1597 1594 1590
Watts 269 334 401 469 539
Cooling 330
CFM/Ton
CFM 1512 1510 1509 1506 1501
Watts 230 291 354 419 485
Cooling 310
CFM/Ton
CFM 1423 1421 1419 1417 1412
Watts 195 252 312 373 436
Cooling 290
CFM/Ton
CFM 1334 1331 1329 1327 1323
Watts 163 217 274 332 392
Cooling
5.0 Ton
(a)
Cooling 450
CFM/Ton
CFM 2249 2246 2241 2236 2228
Watts 722 815 909 1004 1101
Cooling 420
CFM/Ton
CFM 2108 2105 2101 2096 2090
Watts 595 681 770 859 949
Cooling 400
CFM/Ton
CFM 2013 2010 2007 2003 1997
Watts 519 602 685 771 857
Cooling 370
CFM/Ton
CFM 1869 1867 1864 1860 1855
Watts 418 494 572 651 731
Cooling 350
CFM/Ton
(a)
CFM 1772 1770 1768 1764 1759
Watts 359 431 505 580 656
Cooling 330
CFM/Ton
CFM 1675 1673 1671 1667 1663
Watts 305 374 443 514 587
Cooling 310
CFM/Ton
CFM 1576 1575 1573 1570 1565
Watts 258 322 388 455 523
Cooling 290
CFM/Ton
CFM 1478 1476 1474 1471 1467
Watts 216 276 337 401 466
(a)
Factory Setting.
Table 19. S9V2D120U5PSC Heating Airflow
S9V2D120U5PSC Furnace Heating Airflow (CFM), Temp. Rise (°F), and Power (Watts) vs. External Static Pressure with
Filter (iwc)
1st Stage Capacity = 75,500
2nd Stage Capacity = 115,700
Heating
Airflow
Setting
Target
Airflow
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Heating 1st
Stage
Low 1123
CFM 1138 1158 1178 1198 1218
Temp. Rise
61 60 59 58 57
Watts 115 176 236 297 358
Medium Low 1332
CFM 1371 1383 1394 1406 1417
Temp. Rise
51 50 50 49 49
Watts 182 251 320 389 457
Medium
(a)
1404
CFM 1440 1450 1461 1471 1482
Temp. Rise
48 48 48 47 47
Watts 208 283 357 431 505
High
1620
CFM 1669 1674 1680 1685 1691
Temp. Rise
42 42 41 41 41
Watts 315 388 460 533 605
Heating 2nd
Stage
Low 1560
CFM 1654 1637 1621 1604 1587
Temp. Rise
65 66 67 67 68
Watts 291 360 430 499 568
Medium Low 1850
CFM 1980 1951 1922 1893 1864
Temp. Rise
55 56 57 58 58
Watts 456 539 621 704 787
Medium
(a)
1950
CFM 2075 2037 1999 1961 1923
Temp. Rise
52 53 54 55 56
Watts 527 611 696 781 865
High
2250
CFM 2280 2197 2114 2032 1949
Temp. Rise
48 50 52 54 56
Watts 795 819 842 865 888
(a)
Factory Setting.
HHeeaattiinngg aanndd CCoooolliinngg AAiirrffllooww TTaabblleess
