Trane S9V2B040U3PSC User Manual

S9V2-SVX001-1B-EN
31
Table 20. S9V2D120D5PSC Heating Airflow
S9V2D120D5PSC Furnace Heating Airflow (CFM), Temp. Rise (°F), and Power (Watts) vs. External Static Pressure with
Filter (iwc)
1st Stage Capacity = 75,800
2nd Stage Capacity = 116,100
Heating
Airflow
Setting
Target
Airflow
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Heating 1st
Stage
Low 1160
CFM 1234 1240 1246 1252 1258
Temp. Rise
56 56 56 55 55
Watts 137 198 258 319 380
Medium Low 1332
CFM 1305 1311 1318 1325 1332
Temp. Rise
53 53 53 52 52
Watts 158 221 284 347 410
Medium 1404
CFM 1324 1510 1697 1884 2070
Temp. Rise
53 46 39 32 25
Watts 179 246 313 380 447
High
(a)
1620
CFM 1598 1484 1371 1257 1144
Temp. Rise
44 47 49 52 54
Watts 266 316 366 416 466
Heating 2nd
Stage
Low 1750
CFM 1687 1673 1659 1645 1631
Temp. Rise
63 64 64 65 65
Watts 327 407 487 568 648
Medium Low 1850
CFM 1788 1771 1754 1738 1721
Temp. Rise
60 60 61 61 62
Watts 380 464 549 633 718
Medium 1950
CFM 1891 1862 1833 1803 1774
Temp. Rise
56 57 58 60 61
Watts 424 524 624 724 824
High
(a)
2250
CFM 2080 2100 2120 2140 2160
Temp. Rise
51 51 51 51 51
Watts 708 768 828 888 948
(a)
Factory Setting.
Table 21. S9V2D120U5PSC / S9V2D120D5PSC Cooling Airflow
S9V2D120U5PSC / S9V2D120D5PSC Furnace Cooling Airflow (CFM) and Power (Watts) vs. External Static Pressure with
Filter (iwc)
Cooling
Unit Outdoor
Airflow
Setting
(CFM/ton)
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Cooling
3.0 Ton
Cooling 450
CFM/Ton
CFM 1336 1346 1354 1360 1363
Watts 163 221 281 341 402
Cooling 420
CFM/Ton
CFM 1248 1258 1265 1271 1274
Watts 137 191 247 304 361
Cooling 400
CFM/Ton
CFM 1189 1199 1206 1211 1214
Watts 121 173 227 281 336
Cooling 370
CFM/Ton
CFM 1102 1110 1116 1121 1123
Watts 100 148 198 249 301
Cooling 350
CFM/Ton
CFM 1043 1051 1057 1060 1062
Watts 87 133 181 230 279
Cooling 330
CFM/Ton
CFM 985 991 996 999 1000
Watts 76 119 165 211 259
Cooling 310
CFM/Ton
CFM 927 932 936 937 938
Watts 65 107 150 195 241
Cooling 290
CFM/Ton
CFM 869 872 874 875 875
Watts 56 95 136 179 223
Cooling
3.5 Ton
Cooling 450
CFM/Ton
CFM 1559 1567 1574 1579 1583
Watts 244 312 381 450 519
Cooling 420
CFM/Ton
CFM 1455 1464 1472 1477 1481
Watts 204 267 331 396 462
Cooling 400
CFM/Ton
CFM 1386 1395 1403 1409 1413
Watts 179 240 301 363 426
Cooling 370
CFM/Ton
CFM 1282 1292 1300 1305 1309
Watts 147 203 260 318 376
Cooling 350
CFM/Ton
CFM 1214 1223 1231 1236 1239
Watts 127 181 235 290 346
Cooling 330
CFM/Ton
CFM 1145 1154 1161 1166 1169
Watts 110 160 212 265 318
Cooling 310
CFM/Ton
CFM 1077 1085 1092 1096 1098
Watts 94 142 191 241 292
Cooling 290
CFM/Ton
CFM 1009 1016 1021 1025 1026
Watts 80 125 171 219 267
HHeeaattiinngg aanndd CCoooolliinngg AAiirrffllooww TTaabblleess
