32
S9V2-SVX001-1B-EN
Table 21. S9V2D120U5PSC / S9V2D120D5PSC Cooling Airflow (continued)
S9V2D120U5PSC / S9V2D120D5PSC Furnace Cooling Airflow (CFM) and Power (Watts) vs. External Static Pressure with
Filter (iwc)
Cooling
Unit Outdoor
Airflow
Setting
(CFM/ton)
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Cooling
4.0 Ton
Cooling 450
CFM/Ton
CFM 1783 1789 1793 1796 1798
Watts 350 427 505 584 663
Cooling 420
CFM/Ton
CFM 1663 1671 1677 1681 1683
Watts 290 362 436 509 583
Cooling 400
CFM/Ton
CFM 1584 1592 1599 1603 1607
Watts 255 324 393 464 534
Cooling 370
CFM/Ton
CFM 1465 1474 1481 1487 1491
Watts 207 271 336 401 467
Cooling 350
CFM/Ton
CFM 1386 1395 1403 1409 1413
Watts 179 240 301 363 426
Cooling 330
CFM/Ton
CFM 1307 1317 1324 1330 1334
Watts 154 211 269 328 388
Cooling 310
CFM/Ton
CFM 1228 1238 1246 1251 1254
Watts 131 185 240 296 352
Cooling 290
CFM/Ton
CFM 1150 1159 1166 1171 1174
Watts 111 162 214 266 320
Cooling
4.5 Ton
Cooling 450
CFM/Ton
CFM 2010 2011 2012 2011 2010
Watts 482 569 657 745 834
Cooling 420
CFM/Ton
CFM 1874 1878 1881 1882 1883
Watts 399 480 562 645 727
Cooling 400
CFM/Ton
CFM 1783 1789 1793 1796 1798
Watts 350 427 505 584 663
Cooling 370
CFM/Ton
CFM 1648 1656 1662 1666 1669
Watts 283 355 427 500 574
Cooling 350
CFM/Ton
CFM 1559 1567 1574 1579 1583
Watts 244 312 381 450 519
Cooling 330
CFM/Ton
CFM 1470 1479 1486 1492 1495
Watts 209 273 338 404 469
Cooling 310
CFM/Ton
CFM 1381 1390 1398 1404 1408
Watts 178 238 299 361 423
Cooling 290
CFM/Ton
CFM 1292 1302 1310 1315 1319
Watts 149 206 264 322 381
Cooling
5.0 Ton
(a)
Cooling 450
CFM/Ton
CFM 2238 2235 2230 2226 2220
Watts 646 742 840 938 1036
Cooling 420
CFM/Ton
CFM 2086 2086 2085 2083 2080
Watts 533 623 714 806 897
Cooling 400
CFM/Ton
CFM 1985 1987 1988 1988 1986
Watts 466 552 639 726 813
Cooling 370
CFM/Ton
CFM 1834 1838 1842 1844 1845
Watts 377 456 536 617 698
Cooling 350
CFM/Ton
(a)
CFM 1733 1740 1745 1748 1750
Watts 324 399 475 552 628
Cooling 330
CFM/Ton
CFM 1633 1641 1647 1652 1655
Watts 277 347 419 492 564
Cooling 310
CFM/Ton
CFM 1534 1543 1550 1555 1558
Watts 234 301 369 437 505
Cooling 290
CFM/Ton
CFM 1435 1444 1452 1458 1461
Watts 196 259 322 387 451
(a)
Factory Setting.
