2-0* DC Brakes
Parameter group for configuring the DC brake and DC hold functions.
2-00 DC Hold/Preheat Current
Range: Function:
50 %* [Application dependant] Enter a value for holding current as a percentage of the rated motor cur-
rent I
M,N
set in par.1-24
Motor Current. 100% DC holding current corre-
sponds to I
M,N
.
This parameter holds the motor (holding torque) or pre-heats the motor.
This parameter is active if [1] DC hold/Preheat is selected in par.
1-80
Function at Stop.
NOTE
The maximum value depends on the rated motor current.
Avoid 100% current for too long. It may damage t
he motor.
2-01 DC Brake Current
Range: Function:
50 %* [Application dependant] Enter a value for current as a percentage of the rated motor current
I
M,N
, see par.1-24
Motor Current. 100% DC braking current corresponds
to I
M,N
.
DC brake current is applied on a stop command, when the speed is lower
than the limit set in par.2-03
DC Brake Cut-in Speed [RPM]; when the DC
Brake Inverse function is active; or via the serial communication port.
The braking current is active during the time period set in par.2-02
DC
Braking Time.
NOTE
The maximum value depends on the rated motor current.
Avoid 100% current for too long, as it may damag
e the motor. It may damage the motor.
2-02 DC Braking Time
Range: Function:
10.0 s* [0.0 - 60.0 s] Set the duration of the DC braking current set in par.2-01
DC Brake Cur-
rent, once activated.
2-03 DC Brake Cut-in Speed [RPM]
Range: Function:
Applica-
tion de-
pend-
ent*
[Application dependant]
