NOTE
In applications requiring UL listing, when the frequency
converter is supplied with a contactor, the customer must
provide external fusing to maintain the UL rating of the
frequency converter and a short circuit current rating of
100,000 A. See 10.1.1 Power-dependent Specifications for
fuse recommendations.
2.7.8 Circuit Breaker
Table 2.14 provides details on the type of circuit breaker
provided as an option with the various units and power
ranges.
Voltage Frequency converter
model
Circuit breaker manufacturer
and type
380–500 V N110T5–N132T5 ABB T5L400TW
N160T5 ABB T5LQ400TW
N200T5 ABB T6L600TW
N250T5 ABB T6LQ600TW
N315T5 ABB T6LQ800TW
525–690 V N75KT7–N160T7 ABB T5L400TW
N200T7–N315T7 ABB T6L600TW
N400T7 ABB T6LQ600TW
Table 2.14
TR200 D-Frame Operating Instructions Installation
BAS-SVX54B-EN
31
