10.3 Fuse Tables
10.3.1 Protection
Branch Circuit Protection
In order to protect the installation against electrical and
fire hazard, all branch circuits in an installation, switch
gear, machines etc., must be short-circuited and over-
current protected according to national/international
regulations.
Short-circuit Protection
The frequency converter must be protected against short-
circuit to avoid electrical or fire hazard. Trane recommends
using the fuses mentioned below to protect service
personnel and equipment in case of an internal failure in
the frequency converter. The frequency converter provides
full short-circuit protection in case of a short-circuit on the
motor output.
Over-current Protection
Provide overload protection to avoid fire hazard due to
overheating of the cables in the installation. The frequency
converter is equipped with an internal over-current
protection that can be used for upstream overload
protection (UL-applications excluded). See 4-18 Current
Limit. Moreover, fuses or circuit breakers can be used to
provide the over-current protection in the installation.
Over-current protection must always be carried out
according to national regulations.
10.3.2 Fuse Selection
Trane recommends using the following fuses which will
ensure compliance with EN50178. In case of malfunction,
not following the recommendation may result in
unnecessary damage to the frequency converter.
The fuses below are suitable for use on a circuit capable of
delivering 100,000 Arms (symmetrical).
N110-N315 380–500 V type aR
N75K–N400 525–690 V type aR
Table 10.5
Power
Size
Fuse options
Bussman
PN
Littelfuse PN Littelfuse
PN
Bussmann
PN
Siba PN Ferraz-Shawmut
PN
Ferraz-Shawmut PN
(Europe)
Ferraz-Shawmut PN
(North America)
N110 170M2619 LA50QS300-4 L50S-300 FWH-300A 20 610
31.315
A50QS300-4 6,9URD31D08A0315 A070URD31KI0315
N132 170M2620 LA50QS350-4 L50S-350 FWH-350A 20 610
31.350
A50QS350-4 6,9URD31D08A0350 A070URD31KI0350
N160 170M2621 LA50QS400-4 L50S-400 FWH-400A 20 610
31.400
A50QS400-4 6,9URD31D08A0400 A070URD31KI0400
N200 170M4015 LA50QS500-4 L50S-500 FWH-500A 20 610
31.550
A50QS500-4 6,9URD31D08A0550 A070URD31KI0550
N250 170M4016 LA50QS600-4 L50S-600 FWH-600A 20 610
31.630
A50QS600-4 6,9URD31D08A0630 A070URD31KI0630
N315 170M4017 LA50QS800-4 L50S-800 FWH-800A 20 610
31.800
A50QS800-4 6,9URD32D08A0800 A070URD31KI0800
Table 10.6 Fuse Options for 380-480 V Frequency Converters
