Trane TR200 - Parameter Menu Structure

Parameter International
default parameter
value
North American
default parameter
value
22-85 Speed at
Design Point [RPM]
See Note 3
1500 RPM 1800 RPM
22-86 Speed at
Design Point [Hz]
50 Hz 60 Hz
24-04 Fire Mode
Max Reference
50 Hz 60 Hz
Table 5.1 International/North American Default Parameter Settings
5.5 Parameter Menu Structure
Establishing the correct programming for applications
often requires setting functions in several related
parameters. These parameter settings provide the
frequency converter with system details it needs to
operate properly. System details may include such things
as input and output signal types, programming terminals,
minimum and maximum signal ranges, custom displays,
automatic restart, and other features.
•
See the LCP display to view detailed parameter
programming and setting options
•
Press [Info] in any menu location to view
additional details for that function
•
Press and hold [Main Menu] to enter a parameter
number for direct access to that parameter
•
Details for common application set ups are
provided in Chapter6 Application Examples
TR200 D-Frame Operating Instructions Programming
BAS-SVX54B-EN
43
