36-3* Analog Input X49/5
36-30 Terminal X49/5 Low Voltage
36-31 Terminal X49/5 Low Current
36-32 Terminal X49/5 High Voltage
36-33 Terminal X49/5 High Current
36-34 Term. X49/5 Low Ref./Feedb. Value
36-35 Term. X49/5 High Ref./Feedb. Value
36-36 Term. X49/5 Filter Time Constant
36-37 Term. X49/5 Live Zero
36-4* Output X49/7
36-40 Terminal X49/7 Analogue Output
36-41 Terminal X49/7 Digital Output
36-42 Terminal X49/7 Min. Scale
36-43 Terminal X49/7 Max. Scale
36-44 Terminal X49/7 Bus Control
36-45 Terminal X49/7 Timeout Preset
36-5* Output X49/9
36-50 Terminal X49/9 Analogue Output
36-51 Terminal X49/9 Digital Output
36-52 Terminal X49/9 Min. Scale
36-53 Terminal X49/9 Max. Scale
36-54 Terminal X49/9 Bus Control
36-55 Terminal X49/9 Timeout Preset
36-6* Output X49/11
36-60 Terminal X49/11 Analogue Output
36-61 Terminal X49/11 Digital Output
36-62 Terminal X49/11 Min. Scale
36-63 Terminal X49/11 Max. Scale
36-64 Terminal X49/11 Bus Control
36-65 Terminal X49/11 Timeout Preset
99-* Devel support
99-0* DSP Debug
99-00 DAC 1 selection
99-01 DAC 2 selection
99-02 DAC 3 selection
99-03 DAC 4 selection
99-04 DAC 1 scale
99-05 DAC 2 scale
99-06 DAC 3 scale
99-07 DAC 4 scale
99-08 Test param 1
99-09 Test param 2
99-10 DAC Option Slot
99-1* Hardware Control
99-11 RFI 2
99-12 Fan
99-1* Software Readouts
99-13 Idle time
99-14 Paramdb requests in queue
99-15 Secondary Timer at Inverter Fault
99-16 No of Current Sensors
99-2* Heatsink Readouts
99-20 HS Temp. (PC1)
99-21 HS Temp. (PC2)
99-22 HS Temp. (PC3)
99-23 HS Temp. (PC4)
99-24 HS Temp. (PC5)
99-25 HS Temp. (PC6)
99-26 HS Temp. (PC7)
99-27 HS Temp. (PC8)
99-2* Platform Readouts
99-29 Platform Version
99-5* PC Debug
99-50 PC Debug Selection
99-51 PC Debug 0
99-52 PC Debug 1
99-53 PC Debug 2
99-54 PC Debug 3
99-55 PC Debug 4
99-56 Fan 1 Feedback
99-57 Fan 2 Feedback
99-58 PC Auxiliary Temp
99-59 Power Card Temp.
99-9* Internal Values
99-90 Options present
99-91 Motor Power Internal
99-92 Motor Voltage Internal
99-93 Motor Frequency Internal
99-94 Imbalance derate [%]
99-95 Temperature derate [%]
99-96 Overload derate [%]
TR200 D-Frame Operating Instructions Programming
BAS-SVX54B-EN
47
To Next Page
