Trane Tracer User Manual

VAV-SVX07B-EN 21
Wiring Installation
Power On Check
1. Verify that the 24 Vac connector and the chassis ground are properly wired.
2. Remove the lockout/tagout from the line voltage power to the electrical cabinet.
3. Energize the transformer to apply power to the UC400 controller.
4. Observe the UC400 controller when power is applied to verify the power check sequence as
follows:
a. The power LED lights red for 1 second, then;
b. The power LED lights green.
Note: If the sequence completes as described, the controller is properly booted and ready for
the application code. If the power LED flashes red, a fault condition exists.

Trane Tracer Specifications

General

Manufacturer	Trane
Memory	Varies by model
Dimensions	Varies by model
Weight	Varies by model
Model	Tracer
Communication Protocols	BACnet
User Interface	Web-based
Network Compatibility	Ethernet, RS-485
Category	Controller
Input Voltage	24 VAC
Humidity Range	non-condensing
