VAV-SVX07B-EN 25
Wiring Installation
Binary Output Wiring
Binary outputs that are required for unit operation are factory wired and commissioned. The UC400
controller does have extra binary outputs available for other use with most configurations. To
program the extra outputs on the UC400 controller, refer to the Tracer UC400 Programmable
Controller Installation, Operation, and Maintenance Manual (BAS-SVX20) and the Application
Guide for UC400 VAV Operation (BAS-APG010).
