Dual Display
The 8000 Series multimeters incorporate clear, bright dual vacuum fluorescent displays to present
the user with a large amount of information in an easy to read configuration.
The main display shows the reading, function selected and various indicators depending on the
mode of operation (for example, an āsā to indicate a sample being taken).
The secondary two line display shows additional settings related to the modes selected, including
FILTER, RANGE, TERMINAL SELECTION. In addition the secondary display is also available to
display menu options and settings.
Example Status Display : User Menu
Main Display Area
