8000 SERIES OPERATION MANUAL TRANSMILLE LTD.
TRANSMILLE LTD. PAGE 59
Example 1 : DC Voltage 10V Range
Calibration Point Actions
DC Voltage
ZERO
Apply low thermal shorting link
Select Calibration Zero
Press ENTER
DC Voltage
+ve Full Scale
Apply +10V signal
Select +ve Full Scale
Press ENTER
DC Voltage
-ve Full Scale
Apply -10V signal
Select -ve Full Scale
Press ENTER
Example 2 : AC Voltage 10V Range
Calibration Point Actions Frequency Points
AC Voltage
20% FS
Apply 20% FS signal (2V)
Select 20% Full Scale
Press ENTER
AC Voltage
+ve Full Scale
Apply +10V signal
Select +ve Full Scale
Press ENTER
Frequency Response points* :
1kHz (Reference Frequency)**
10Hz
23Hz
40Hz
56Hz
106Hz
206Hz
2kHz
1kHz**
10kHz
20kHz
35kHz
50kHz
75kHz
100kHz
200kHz
400kHz
700kHz
1MHz
* Max. Frequency dependant on range
** 1kHz reference frequency point
MUST be set up first
Linearity is inherent within the design of the D to A in the multimeter
and does not require adjustment.
