8000 SERIES OPERATION MANUAL TRANSMILLE LTD.
TRANSMILLE LTD. PAGE 58
The calibration menus will change depending on the selected function :
Function Menus Available Notes
DC Voltage
DC Current
Calibration Zero
Calibration +ve Full Scale
Calibration -ve Full Scale
Value <range units>
Reset
Set zero calibration point
Set +FS calibration point
Set -FS calibration point
Calibrate FS to set value
Reset range to default points
AC Voltage
AC Current
Calibration 20% FS
Calibration +ve Full Scale
Value <range units>
Reset
Set 20% FS calibration point
Set +FS calibration point
Calibrate FS to set value
Reset range to default points
Frequency Response points* :
1kHz (Reference Frequency)**
10Hz
23Hz
40Hz
56Hz
106Hz
206Hz
2kHz
1kHz**
10kHz
20kHz
35kHz
50kHz
75kHz
100kHz
200kHz
400kHz
700kHz
1MHz
* Max. Frequency dependant on range
** 1kHz reference frequency point
MUST be set up first
Resistance 2 Wire
Resistance 4 Wire
Calibration Zero
Calibration +ve Full Scale
Value <range units>
Reset
Set zero calibration point
Set +FS calibration point
Calibrate FS to set value
Reset range to default points
