FMS-2000M
LIT-12013580
18
rooms. These include isolation mode, the ability to name the room or parameter, and the ability to set up the door switch if you install it.
Naming the device or parameter
If you monitor more than one room, the name that you input appears at the top of each room tile on the home screen.
1. On the home screen, tap the Settings icon to enter the settings menu.
2. To view rooms settings, tap Room.
3. On the room screen, tap the Name arrow.
4. Enter a name. It can be up to 14 characters in portrait mode and up to 16 characters in landscape mode.
5. Checkmark icon.
Changing the isolation mode
Isolation mode controls the isolation mode options that are available in the restricted level user’s menu and in the isolation mode quick
link on the home screen. The isolation mode quick link is only available on single sensor models.
However, you can adjust the alarm limits to correlate with a positive or negative isolation mode.
• Positive and neutral
• Negative and neutral
• Positive, negative, and neutral
To change the isolation mode, complete the following steps:
1. On the home screen, tap the Settings icon to enter the settings menu.
2. To view room settings, tap Room.
3. To adjust the isolation mode, expand Isolation Mode and choose from the following options:
• Positive Only
• Negative Only
• Positive and Negative
4. To save the new settings, collapse Isolation Mode.
Conguring the door switch
If you install a door switch, you can enable the door switch, adjust the switch type, and adjust the alarm delay. The door switch reduces
false positive alarms each time the door opens. Instead, the audible alarm is silent and a yellow warning screen appears and the 360°
1. On the home screen, tap the Settings icon to enter the settings menu.
2. To view room settings, tap Room.
3. On the room screen, tap the arrow next to Door Switch.
4. On the door switch screen, tap the toggle button to turn the door switch on.
5. Expand Switch Type and choose from the following options:
• Normally Open
• Normally Closed
6. Switch Type.
Setting up a delay
audible alarm until the room returns to normal operating pressure. The door switch delay has a maximum duration of 240 seconds.
To set up a delay, complete the following steps:
1. On the home screen, tap the Settings icon to enter the settings menu.
2. To view digital input settings, tap Digital Input.
3. On the Digital Input 1 screen, expand Delay and move the slider to adjust the duration of the delay.
4. Checkmark.
Network variables
The FMS-2000M can read network variables over the BMS and display the network variables on the home screen. If you wire the
monitor to the BMS in accordance with the BACnet objects below, the network variable automatically appears on the home screen.
Room setup
